Sony HCD-GR8 - PANEL

– 114 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W
**************************************************************
* A-4398-184-A PANEL BOARD, COMPLETE (GR8: EA3, MY)
* A-4392-825-A PANEL BOARD, COMPLETE
(GR8: EA4, TH, SAF)
* A-4392-383-A PANEL BOARD, COMPLETE
(GR8: AUS, E, HK, IA, JE, MX, SP, TW)
* A-4392-381-A PANEL BOARD, COMPLETE
(RX90: AEP, G, UK, AED)
* A-4392-382-A PANEL BOARD, COMPLETE (RX90: EE, CIS)
**********************
* 4-932-810-11 CUSHION (FL)
* 4-986-870-01 HOLDER, FL TUBE
< CAPACITOR >
C601 1-162-294-31 CERAMIC 0.001uF 10% 50V
C602 1-162-306-11 CERAMIC 0.01uF 20% 16V
C603 1-124-589-11 ELECT 47uF 20% 16V
C604 1-126-163-11 ELECT 4.7uF 20% 50V
C605 1-162-294-31 CERAMIC 0.001uF 10% 50V
C606 1-126-160-11 ELECT 1uF 20% 50V
C607 1-126-160-11 ELECT 1uF 20% 50V
C608 1-162-294-31 CERAMIC 0.001uF 10% 50V
C609 1-162-282-31 CERAMIC 100PF 10% 50V
C610 1-162-282-31 CERAMIC 100PF 10% 50V
C611 1-162-282-31 CERAMIC 100PF 10% 50V
C612 1-162-282-31 CERAMIC 100PF 10% 50V
C613 1-162-282-31 CERAMIC 100PF 10% 50V
C614 1-162-282-31 CERAMIC 100PF 10% 50V
C615 1-162-282-31 CERAMIC 100PF 10% 50V
C616 1-162-282-31 CERAMIC 100PF 10% 50V
C617 1-162-282-31 CERAMIC 100PF 10% 50V
C618 1-162-282-31 CERAMIC 100PF 10% 50V
C619 1-162-282-31 CERAMIC 100PF 10% 50V
C620 1-162-282-31 CERAMIC 100PF 10% 50V
C621 1-162-282-31 CERAMIC 100PF 10% 50V
C622 1-162-282-31 CERAMIC 100PF 10% 50V
C623 1-162-282-31 CERAMIC 100PF 10% 50V
C624 1-162-290-31 CERAMIC 470PF 10% 50V
C625 1-162-294-31 CERAMIC 0.001uF 10% 50V
C626 1-124-589-11 ELECT 47uF 20% 16V
C627 1-162-306-11 CERAMIC 0.01uF 20% 16V
C628 1-162-306-11 CERAMIC 0.01uF 20% 16V
C629 1-162-306-11 CERAMIC 0.01uF 20% 16V
C630 1-162-306-11 CERAMIC 0.01uF 20% 16V
MOTOR
MOTOR BOARD
*************
(Included in AUDIO BOARD, COMPLETE)
< CAPACITOR >
C651 1-161-494-00 CERAMIC 0.022uF 25V
**************************************************************
* 1-658-578-11 MOTOR (SLIDE) BOARD
********************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 20% 16V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-124-907-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-010-43 DIODE UZ-5.6BSC
D804 8-719-987-63 DIODE 1N4148M
D805 8-719-987-63 DIODE 1N4148M
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY (OPEN/CLOSE DET)
**************************************************************
* 1-658-577-11 MOTOR (TURN) BOARD
*******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-124-907-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-010-23 DIODE UZ-3.6BSB
MOTOR (SLIDE) PANELMOTOR (TURN)
