Sony HCD-GR8 - TCB

– 118 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R736 1-249-421-11 CARBON 2.2K 5% 1/4W
R737 1-247-843-11 CARBON 3.3K 5% 1/4W
R738 1-249-427-11 CARBON 6.8K 5% 1/4W
R739 1-249-431-11 CARBON 15K 5% 1/4W
R740 1-247-807-31 CARBON 100 5% 1/4W
R741 1-247-807-31 CARBON 100 5% 1/4W
R742 1-247-807-31 CARBON 100 5% 1/4W
R743 1-249-409-11 CARBON 220 5% 1/4W
R744 1-247-807-31 CARBON 100 5% 1/4W
R745 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S655 1-554-303-21 SWITCH, TACTILE (·: DECK B)
S656 1-554-303-21 SWITCH, TACTILE (ª: DECK B)
S657 1-554-303-21 SWITCH, TACTILE (): DECK B)
S658 1-554-303-21 SWITCH, TACTILE (0: DECK B)
S659 1-554-303-21 SWITCH, TACTILE (p: DECK B)
S660 1-554-303-21 SWITCH, TACTILE (P: PAUSE)
S661 1-554-303-21 SWITCH, TACTILE (r: REC)
S662 1-554-303-21 SWITCH, TACTILE (CD SYNCHRO)
S663 1-554-303-21 SWITCH, TACTILE (HIGH SPEED DUBBING)
S664 1-554-303-21 SWITCH, TACTILE (): DECK A)
S665 1-554-303-21 SWITCH, TACTILE (0: DECK A)
S666 1-554-303-21 SWITCH, TACTILE (p: DECK A)
S667 1-554-303-21 SWITCH, TACTILE (·: DECK A)
S668 1-554-303-21 SWITCH, TACTILE (ª:DECK A)
**************************************************************
A-4303-508-A TCB BOARD, COMPLETE (GR8: JE)
A-4303-571-A TCB BOARD, COMPLETE
(RX90: AEP, G, UK, AED)
A-4303-570-A TCB BOARD, COMPLETE (RX90: EE, CIS)
********************
< CAPACITOR >
C1 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
(GR8: JE/RX90)
C2 1-126-967-11 ELECT 47uF 20% 16V
(GR8: JE/RX90)
C3 1-163-038-91 CERAMIC (2012) 100000PF 25V
(GR8: JE/RX90)
C5 1-163-031-11 CERAMIC (2012) 10000PF 50V
(GR8: JE/RX90)
C6 1-163-038-91 CERAMIC (2012) 100000PF 25V
(GR8: JE/RX90)
C7 1-101-004-00 CERAMIC 0.01uF 50V
(GE8: JE/RX90: EE, CIS)
C8 1-163-031-11 CERAMIC (2012) 10000PF 50V
(GR8: JE/RX90)
C9 1-163-031-11 CERAMIC (2012) 10000PF 50V
(GR8: JE/RX90)
C10 1-163-031-11 CERAMIC (2012) 10000PF 50V
(GR8: JE/RX90)
C11 1-163-038-91 CERAMIC (2012) 100000PF 25V
(GR8: JE)
R861 1-249-417-11 CARBON 1K 5% 1/4W
R862 1-249-431-11 CARBON 15K 5% 1/4W
R863 1-249-441-11 CARBON 100K 5% 1/4W
< THERMISTOR >
TH801 1-807-796-11 THERMISTOR
**************************************************************
* 1-658-576-11 SENSOR BOARD
*************
< IC >
IC702 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
IC703 8-749-924-30 IC PHOTO REFLECTOR GP2S28
< RESISTOR >
R701 1-249-416-11 CARBON 820 5% 1/4W
R702 1-249-407-11 CARBON 150 5% 1/4W
**************************************************************
* 1-664-024-11 TC SW BOARD
************
< CONNECTOR >
CN607 1-506-486-11 PIN, CONNECTOR 7P
< DIODE >
D634 8-719-063-92 DIODE SLR325MC-M-T31-NP (·: DECK B)
D635 8-719-063-92 DIODE SLR325MC-M-T31-NP (ª: DECK B)
D636 8-719-063-91 DIODE SLR325DC-P-T32 (P PAUSE)
D637 8-719-063-93 DIODE SLR325VC-N-T32 (r REC)
D638 8-719-063-92 DIODE SLR325MC-M-T31-NP (·: DECK A)
D639 8-719-063-92 DIODE SLR325MC-M-T31-NP (ª: DECK A)
< TRANSISTOR >
Q617 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q618 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q619 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R726 1-249-403-11 CARBON 68 5% 1/4W
R727 1-247-807-31 CARBON 100 5% 1/4W
R728 1-249-407-11 CARBON 150 5% 1/4W
R729 1-249-407-11 CARBON 150 5% 1/4W
R730 1-249-409-11 CARBON 220 5% 1/4W
R731 1-249-411-11 CARBON 330 5% 1/4W
R732 1-249-413-11 CARBON 470 5% 1/4W
R733 1-249-415-11 CARBON 680 5% 1/4W
R734 1-249-417-11 CARBON 1K 5% 1/4W
R735 1-249-419-11 CARBON 1.5K 5% 1/4W
POWER AMP SENSOR TC SW TCB
