Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
41
C732 1-161-494-00 CERAMIC 0.022uF 25V
C733 1-104-664-11 ELECT 47uF 20% 25V
C734 1-126-934-11 ELECT 220uF 20% 16V
C735 1-161-494-00 CERAMIC 0.022uF 25V
C751 1-126-967-11 ELECT 47uF 20% 50V
< CONNECTOR >
* CN701 1-568-837-11 SOCKET, CONNECTOR 20P
* CN703 1-564-510-11 PLUG, CONNECTOR 7P
< DIODE >
D402 8-719-991-33 DIODE 1SS133T-77
D403 8-719-991-33 DIODE 1SS133T-77
D404 8-719-991-33 DIODE 1SS133T-77
D405 8-719-991-33 DIODE 1SS133T-77
D406 8-719-991-33 DIODE 1SS133T-77
D701 8-719-027-23 DIODE GBU6D
D702 8-719-200-02 DIODE 1N4002
D703 8-719-200-02 DIODE 1N4002
D704 8-719-200-02 DIODE 1N4002
D705 8-719-200-02 DIODE 1N4002
D706 8-719-200-02 DIODE 1N4002
D707 8-719-200-02 DIODE 1N4002
D708 8-719-200-02 DIODE 1N4002
D709 8-719-010-73 DIODE UZ-12BSA
D711 8-719-012-33 DIODE UZ-27BSA-TA
D712 8-719-010-57 DIODE UZ-8.2BSA
D713 8-719-991-33 DIODE 1SS133T-77
D714 8-719-010-73 DIODE UZ-12BSA
D716 8-719-947-12 DIODE UZ-4.7BSA
< FUSE >
! F701 1-532-388-31 FUSE TL2.0A 250V
(GRX20:AR,AUS,E,SP,TW/RXD3)
! F701 1-576-104-11 FUSE 2.0A 250V (GRX20:MX)
< IC >
IC401 8-749-015-44 IC STK407-070E
IC402 8-759-111-68 IC uPC1237HA
< JACK >
JK401 1-694-443-11 TERMINAL BOARD (SPEAKER)
< COIL >
L401 1-420-872-00 COIL, AIR-CORE (RXD3)
L402 1-420-872-00 COIL, AIR-CORE (RXD3)
< TRANSISTOR >
Q401 8-729-231-55 TRANSISTOR 2SC2878-A
Q402 8-729-231-55 TRANSISTOR 2SC2878-A
Q403 8-729-184-53 TRANSISTOR 2SC1841-EA
Q404 8-729-184-53 TRANSISTOR 2SC1841-EA
Q405 8-729-140-82 TRANSISTOR 2SA988-FA
Q411 8-729-026-29 TRANSISTOR 2SJ346
Q412 8-729-231-55 TRANSISTOR 2SC2878-A
Q413 8-729-231-55 TRANSISTOR 2SC2878-A
Q701 8-729-822-89 TRANSISTOR 2SD1667
Q702 8-729-188-23 TRANSISTOR 2SD882-P
Q703 8-729-202-67 TRANSISTOR 2SK246-GR3
Q704 8-729-202-67 TRANSISTOR 2SK246-GR3
Q705 8-729-232-32 TRANSISTOR 2SA965-O/Y(TPE6)
< RESISTOR >
R401 1-247-879-11 CARBON 100K 5% 1/4W
R402 1-247-879-11 CARBON 100K 5% 1/4W
R403 1-247-839-11 CARBON 2.2K 5% 1/4W
R404 1-247-839-11 CARBON 2.2K 5% 1/4W
R405 1-249-438-11 CARBON 56K 5% 1/4W
R406 1-249-438-11 CARBON 56K 5% 1/4W
R407 1-249-420-11 CARBON 1.8K 5% 1/4W F
R408 1-249-420-11 CARBON 1.8K 5% 1/4W F
R409 1-249-438-11 CARBON 56K 5% 1/4W
R410 1-249-438-11 CARBON 56K 5% 1/4W
R411 1-260-087-11 CARBON 100 5% 1/2W
R412 1-249-417-11 CARBON 1K 5% 1/4W F
R413 1-249-417-11 CARBON 1K 5% 1/4W F
R414 1-260-087-11 CARBON 100 5% 1/2W
R415 1-249-431-11 CARBON 15K 5% 1/4W
R416 1-249-431-11 CARBON 15K 5% 1/4W
R417 1-260-072-11 CARBON 4.7 5% 1/2W
R418 1-260-072-11 CARBON 4.7 5% 1/2W
R419 1-220-889-11 METAL 0.22 10% 3W
R420 1-220-889-11 METAL 0.22 10% 3W
R421 1-247-879-11 CARBON 100K 5% 1/4W
R422 1-247-879-11 CARBON 100K 5% 1/4W
R423 1-247-839-11 CARBON 2.2K 5% 1/4W
R424 1-249-430-11 CARBON 12K 5% 1/4W
R425 1-249-430-11 CARBON 12K 5% 1/4W
R426 1-247-871-11 CARBON 47K 5% 1/4W
R427 1-249-417-11 CARBON 1K 5% 1/4W F
R428 1-249-438-11 CARBON 56K 5% 1/4W
R429 1-247-855-11 CARBON 10K 5% 1/4W
R430 1-247-879-11 CARBON 100K 5% 1/4W
R432 1-247-847-11 CARBON 4.7K 5% 1/4W
R434 1-260-072-11 CARBON 4.7 5% 1/2W
(RXD3)
R435 1-260-072-11 CARBON 4.7 5% 1/2W
(RXD3)
R442 1-247-835-11 CARBON 1.5K 5% 1/4W
R443 1-247-903-00 CARBON 1M 5% 1/4W
R444 1-249-393-11 CARBON 10 5% 1/4W F
R446 1-247-862-11 CARBON 20K 5% 1/4W
R448 1-247-843-11 CARBON 3.3K 5% 1/4W
R449 1-247-843-11 CARBON 3.3K 5% 1/4W
R451 1-247-879-11 CARBON 100K 5% 1/4W
R455 1-215-867-00 METAL OXIDE 470 5% 1W F
R456 1-215-867-00 METAL OXIDE 470 5% 1W F
R702 1-249-413-11 CARBON 470 5% 1/4W F
R703 1-215-863-11 METAL OXIDE 100 5% 1W F
R704 1-247-847-11 CARBON 4.7K 5% 1/4W
R705 1-247-855-11 CARBON 10K 5% 1/4W
R706 1-215-863-11 METAL OXIDE 100 5% 1W F
R707 1-249-413-11 CARBON 470 5% 1/4W F
R708 1-247-807-11 CARBON 100 5% 1/4W
R709 1-247-807-11 CARBON 100 5% 1/4W
The components identified b y mar k ! or dotted
line with mar k ! are cr itical f or saf ety.
Replace only with par t number specified.
AMPLIFIER
