NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• Abbreviation
AUS : Australian model
G : German model
SP : Singapore model
MX : Mexican model
AR : Argentina model
TW : Taiwan model
AED : North European model
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
40
SECTION 8
ELECTRICAL PARTS LIST
1-674-880-1 AC SWITCH BOARD (GRX20:AR,E,MX,SP,TW)
****************
< SWITCH >
! SW401 1-771-477-11 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(GRX20:AR,E,MX,SP,TW)
************************************************************
A-4426-292-A AMPLIFIER BOARD, COMPLETE (RXD3)
*************************
A-4426-293-A AMPLIFIER BOARD, COMPLETE (GRX20:AUS)
*************************
A-4426-294-A AMPLIFIER BOARD, COMPLETE
(GRX20:AR,E,MX,SP,TW)
*************************
* 1-533-213-31 HOLDER, FUSE
< CAPACITOR >
C401 1-126-961-11 ELECT 2.2uF 20% 50V
C402 1-126-961-11 ELECT 2.2uF 20% 50V
C403 1-162-294-31 CERAMIC 0.001uF 10% 50V
C404 1-162-294-31 CERAMIC 0.001uF 10% 50V
C405 1-104-664-11 ELECT 47uF 20% 25V
C406 1-104-664-11 ELECT 47uF 20% 25V
C407 1-126-968-11 ELECT 100uF 20% 50V
(GRX20:AR,E,MX,SP,TW/RXD3)
C407 1-128-576-11 ELECT 100uF 20% 63V
(GRX20:AUS)
C408 1-126-968-11 ELECT 100uF 20% 50V
(GRX20:AR,E,MX,SP,TW/RXD3)
C408 1-128-576-11 ELECT 100uF 20% 63V
(GRX20:AUS)
C409 1-130-495-11 MYLAR 0.1uF 5% 50V
C410 1-126-968-11 ELECT 100uF 20% 50V
(GRX20:AR,E,MX,SP,TW/RXD3)
C410 1-128-576-11 ELECT 100uF 20% 63V
(GRX20:AUS)
C411 1-126-968-11 ELECT 100uF 20% 50V
(GRX20:AR,E,MX,SP,TW/RXD3)
C411 1-128-576-11 ELECT 100uF 20% 63V
(GRX20:AUS)
C413 1-162-199-31 CERAMIC 10PF 5% 50V
C414 1-162-199-31 CERAMIC 10PF 5% 50V
C415 1-137-399-11 FILM 0.1uF 5% 100V
C416 1-137-399-11 FILM 0.1uF 5% 100V
C417 1-161-494-00 CERAMIC 0.022uF 25V
C418 1-161-494-00 CERAMIC 0.022uF 25V
C419 1-162-294-31 CERAMIC 0.001uF 10% 50V
C421 1-126-933-11 ELECT 100uF 20% 16V
C422 1-161-494-00 CERAMIC 0.022uF 25V
C423 1-162-294-31 CERAMIC 0.001uF 10% 50V
C424 1-162-294-31 CERAMIC 0.001uF 10% 50V
C425 1-162-294-31 CERAMIC 0.001uF 10% 50V
C426 1-162-294-31 CERAMIC 0.001uF 10% 50V
C427 1-126-963-11 ELECT 4.7uF 20% 50V
C428 1-126-933-11 ELECT 100uF 20% 16V
C429 1-126-960-11 ELECT 1uF 20% 50V
C430 1-109-889-11 ELECT 1uF 20% 50V
C433 1-130-495-11 MYLAR 0.1uF 5% 50V
C497 1-162-282-31 CERAMIC 100PF 10% 50V
C498 1-162-282-31 CERAMIC 100PF 10% 50V
C499 1-161-494-00 CERAMIC 0.022uF 25V
C701 1-126-974-11 ELECT 3300uF 20% 50V
(GRX20:AR,E,MX,SP,TW/RXD3)
C701 1-127-812-11 ELECT 3300uF 20% 63V
(GRX20:AUS)
C702 1-126-974-11 ELECT 3300uF 20% 50V
(GRX20:AR,E,MX,SP,TW/RXD3)
C702 1-127-812-11 ELECT 3300uF 20% 63V
(GRX20:AUS)
C703 1-130-483-00 MYLAR 0.01uF 5% 50V
C704 1-130-483-00 MYLAR 0.01uF 5% 50V
C705 1-130-483-00 MYLAR 0.01uF 5% 50V
C706 1-130-483-00 MYLAR 0.01uF 5% 50V
C707 1-126-968-11 ELECT 100uF 20% 50V
C708 1-161-494-00 CERAMIC 0.022uF 25V
C709 1-161-494-00 CERAMIC 0.022uF 25V
C710 1-128-553-11 ELECT 220uF 20% 63V
C711 1-161-494-00 CERAMIC 0.022uF 25V
C712 1-126-961-11 ELECT 2.2uF 20% 50V
C713 1-126-948-11 ELECT 100uF 20% 35V
C714 1-161-494-00 CERAMIC 0.022uF 25V
C715 1-126-949-11 ELECT 220uF 20% 35V
C716 1-161-494-00 CERAMIC 0.022uF 25V
C717 1-161-494-00 CERAMIC 0.022uF 25V
C718 1-161-494-00 CERAMIC 0.022uF 25V
C719 1-161-494-00 CERAMIC 0.022uF 25V
C720 1-161-494-00 CERAMIC 0.022uF 25V
C721 1-126-943-11 ELECT 2200uF 20% 25V
C722 1-126-933-11 ELECT 100uF 20% 16V
C723 1-161-494-00 CERAMIC 0.022uF 25V
C724 1-161-494-00 CERAMIC 0.022uF 25V
C725 1-126-933-11 ELECT 100uF 20% 16V
C726 1-126-933-11 ELECT 100uF 20% 16V
C727 1-161-494-00 CERAMIC 0.022uF 25V
C728 1-161-494-00 CERAMIC 0.022uF 25V
C729 1-126-935-11 ELECT 470uF 20% 16V
C730 1-161-494-00 CERAMIC 0.022uF 25V
C731 1-161-494-00 CERAMIC 0.022uF 25V
AC SWITCH
AMPLIFIER
