Sony HCD-GRX20 - 2-2. FRONT PANEL; 2-3. MAIN BOARD

6
2-2. FRONT PANEL
2-3. MAIN BOARD
9 Board to board
connectors
(CN602)
(CN601)
MAIN board
3 Harness
(CN303)
1 Three screws
2 Screw
!º Front panel
4 Flat type wir
e
(CN705)
5 Flat type wire
(CN501)
7 Connector
(CN201)
8 Remove the
claws
6 Connector
(to deckB)
6 Five screws
4 CD mechanism deck
2 Two screws
3 Connector
(CN703)
5 Harness (CN701)
1 Harness (CN301)
7 MAIN board
