Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GTR88
72
MIC BOARD
*********
< CAPACITOR >
C700 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C701 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C702 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C707 1-124-257-00 ELECT 2.2uF 20% 50V
C708 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C709 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C710 1-126-157-11 ELECT 10uF 20% 16V
C711 1-124-584-00 ELECT 100uF 20% 6.3V
C712 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C713 1-124-257-00 ELECT 2.2uF 20% 50V
C716 1-124-257-00 ELECT 2.2uF 20% 50V
C719 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C720 1-124-257-00 ELECT 2.2uF 20% 50V
C721 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C722 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C724 1-124-463-00 ELECT 0.1uF 20% 50V
C777 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C779 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C780 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C781 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C782 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< DIODE >
D700 6-501-579-01 DIODE MC2837
D701 6-501-579-01 DIODE MC2837
< IC >
IC700 8-759-278-58 IC NJM4558V-TE2
< JACK >
J700 1-822-757-11 JACK (LARGE TYPE) (MIC)
J702 1-794-702-11 JACK, HEADPHONE (PHONES)
< JUMPER RESISTOR >
JR701 1-216-864-11 SHORT CHIP 0
JR702 1-216-864-11 SHORT CHIP 0
JR703 1-216-296-11 SHORT CHIP 0
JR704 1-216-296-11 SHORT CHIP 0
JR705 1-216-296-11 SHORT CHIP 0
JR706 1-216-296-11 SHORT CHIP 0
JR707 1-216-295-91 SHORT CHIP 0
JR708 1-216-864-11 SHORT CHIP 0
JR709 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R700 1-216-821-11 METAL CHIP 1K 5% 1/10W
R701 1-216-845-11 METAL CHIP 100K 5% 1/10W
R702 1-216-833-11 METAL CHIP 10K 5% 1/10W
R704 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R705 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R706 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R711 1-216-833-11 METAL CHIP 10K 5% 1/10W
R712 1-216-836-11 METAL CHIP 18K 5% 1/10W
R714 1-216-849-11 METAL CHIP 220K 5% 1/10W
R715 1-216-809-11 METAL CHIP 100 5% 1/10W
R716 1-216-845-11 METAL CHIP 100K 5% 1/10W
R720 1-216-845-11 METAL CHIP 100K 5% 1/10W
R721 1-216-836-11 METAL CHIP 18K 5% 1/10W
R722 1-216-833-11 METAL CHIP 10K 5% 1/10W
R723 1-216-836-11 METAL CHIP 18K 5% 1/10W
R724 1-216-841-11 METAL CHIP 47K 5% 1/10W
R725 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VARIABLE RESISTOR >
RV700 1-227-452-11 RES, VAR, CARBON 50K (MIC LEVEL)
*************************************************************
POWER AMP BOARD
*****************
< CAPACITOR >
C1300 1-127-815-11 ELECT (BLOCK) 3300uF 20% 100V
C1301 1-127-815-11 ELECT (BLOCK) 3300uF 20% 100V
C1302 1-127-812-11 ELECT (BLOCK) 3300uF 20% 63V
C1303 1-127-812-11 ELECT (BLOCK) 3300uF 20% 63V
C1304 1-130-777-00 MYLAR 0.1uF 5% 100V
C1305 1-130-777-00 MYLAR 0.1uF 5% 100V
C1306 1-130-777-00 MYLAR 0.1uF 5% 100V
C1307 1-130-777-00 MYLAR 0.1uF 5% 100V
C1308 1-128-582-11 ELECT 10uF 20% 100V
C1309 1-128-582-11 ELECT 10uF 20% 100V
C1310 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C1311 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C1312 1-126-963-11 ELECT 4.7uF 20% 50V
C1313 1-126-963-11 ELECT 4.7uF 20% 50V
C1314 1-164-730-11 CERAMIC CHIP 0.0012uF 10% 50V
C1315 1-164-730-11 CERAMIC CHIP 0.0012uF 10% 50V
C1316 1-107-903-11 ELECT 2.2uF 20% 50V
C1317 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C1318 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C1319 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C1320 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C1321 1-104-658-91 ELECT 100uF 20% 10V
C1322 1-126-947-11 ELECT 47uF 20% 35V
C1323 1-126-947-11 ELECT 47uF 20% 35V
C1324 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C1325 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C1327 1-126-947-11 ELECT 47uF 20% 35V
C1328 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C1329 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C1330 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C1331 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C1332 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C1333 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C1334 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
< CONNECTOR >
CN1300 1-766-719-41 CONNECTOR, BOARD TO BOARD 10P
*
CN1302 1-564-518-11 PLUG, CONNECTOR 3P
CN1303 1-573-825-11 CONNECTOR, BOARD TO BOARD 11P
< DIODE >
D1302 6-500-968-21 DIODE 30PRA20FC
D1303 6-500-968-21 DIODE 30PRA20FC
D1304 6-501-175-01 DIODE UDZW-TE17-11B
D1305 6-501-175-01 DIODE UDZW-TE17-11B
POWER AMPMIC
