Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GTR88
7373
D1306 6-501-817-01 DIODE MA2J1110GLS0
D1307 6-500-334-01 DIODE MC2836-T112-1
D1310 6-501-817-01 DIODE MA2J1110GLS0
< IC >
0
IC1300 6-713-787-01 IC STK412-750-E
< TRANSISTOR >
Q1300 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1301 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1302 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1303 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1304 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1305 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1306 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q1307 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1308 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1309 8-729-027-38 TRANSISTOR DTA144EKA-T146
< RESISTOR >
R1300 1-250-336-11 FUSIBLE 100 5% 1/2W
R1301 1-250-336-11 FUSIBLE 100 5% 1/2W
R1302 1-215-872-11 METAL OXIDE 3.3K 5% 1W
R1303 1-215-872-11 METAL OXIDE 3.3K 5% 1W
R1304 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1305 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1306 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1307 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1308 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1309 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1310 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1311 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1312 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1313 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1314 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1315 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1316 1-250-312-21 METAL CHIP 10 5% 1/2W
R1317 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1318 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1319 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1320 1-250-312-21 METAL CHIP 10 5% 1/2W
R1324 1-217-637-55 FUSIBLE 1 5% 1/4W
R1325 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1326 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1327 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1328 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1329 1-216-820-11 METAL CHIP 820 5% 1/10W
R1330 1-216-820-11 METAL CHIP 820 5% 1/10W
R1331 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1332 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1333 1-216-836-11 METAL CHIP 18K 5% 1/10W
R1334 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1335 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1337 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1338 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1339 1-216-840-11 METAL CHIP 39K 5% 1/10W
R1344 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1345 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1346 1-234-798-11 ENCAPSULATED COMPONENT
R1347 1-234-798-11 ENCAPSULATED COMPONENT
< RELAY >
RY1300 1-755-653-11 RELAY
< TERMINAL >
TB1300 1-820-067-21 TERMINAL BOARD (SPEAKER)
(FRONT SPEAKER)
TB1301 1-820-067-21 TERMINAL BOARD (SPEAKER)
(SATELLITE SPEAKER)
< THERMISTOR >
TH1301 1-804-045-11 THERMISTOR
*************************************************************
SUBTRANS BOARD
****************
< CAPACITOR >
C1200 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1203 1-126-942-61 ELECT 1000uF 20% 25V
C1204 1-126-963-11 ELECT 4.7uF 20% 50V
C1205 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
*
CN1200 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
*
CN1201 1-566-664-11 PIN, CONNECTOR (3.96mm PITCH) 4P
(E2, E51, E4)
*
CN1202 1-568-226-11 PIN, CONNECTOR (3.96mm PITCH) 2P
(MX, AR, AUS)
< DIODE >
D1200 6-501-817-01 DIODE MA2J1110GLS0
D1201 6-500-848-01 DIODE MC2840-T112-1
D1202 6-500-848-01 DIODE MC2840-T112-1
D1203 6-500-335-01 DIODE MC2838-T112-1
< TRANSFORMER >
0
PT1200 1-443-927-21 TRANSFORMER, POWER (SUB) (MX)
0
PT1200 1-445-875-11 POWER TRANSFORMER (SUB) (EXCEPT MX)
< TRANSISTOR >
Q1200 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R1201 1-216-819-11 METAL CHIP 680 5% 1/10W
R1202 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< RELAY >
0
RY1200 1-755-334-11 RELAY, AC POWER
< SWITCH >
0
S1200 1-786-055-31 SELECTOR, VOLTAGE (E2, E51, E4)
*************************************************************
SUBTRANSPOWER AMP
