Sony HCD-HP7 - CD Mechanism Deck (CDM69 CH-K6 BD71 C); Base Unit Section

12
HCD-HP7
3-7. CD Mechanism Deck (CDM69CH-K6BD71C)
3-8. Base Unit Section
4 four screws
(BVTP3 × 8 )
7 CD mechanism deck
(CDM69CH-K6BD71C)
2 two screws
(BVTP3 × 8 )
1 two screws
(BVTP3 × 8 )
6 w ire (flat type)
19p (CN710)
5 w ire (flat type)
27p (CN701)
3 blacket (TR)
4 boss
6 boss
3 boss
5 boss
1 floating screw (+PTPWHM2.6)
2 screw (DIA. 12)
7 base unit section
