Sony HCD-HP7 - Base Unit (BU-K6 BD71 C); BD Board

13
HCD-HP7
3-9. Base Unit (BU-K6BD71C)
3-10. BD Board
q; base unit (BU-K6BD71C)
4 floating screw
(+PTPWHM2.6)
7 insulator (213)
2 floating screw
(+PTPWHM2.6)
9 insulator (213)
3 floating screw
(+PTPWHM2.6)
8 insulator (213)
1 floating screw
(+PTPWHM2.6)
6 insulator (213)
5
2 Remove the solder
(four portions).
4 BD board
3 wire (flat type)
(16core)
1 screw
(BVTP2.6
× 8)
