HCD-HP7
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
ST ENCODER
< TRANSISTOR >
Q501 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q502 6-550-646-01 TRANSISTOR 2SC3143K4/K5-TB
Q503 6-550-646-01 TRANSISTOR 2SC3143K4/K5-TB
Q504 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q505 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q506 8-729-900-36 TRANSISTOR BA1F4M-TP
Q507 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q508 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q509 6-550-289-01 TRANSISTOR 2SA1235F
Q510 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q511 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q512 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q513 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q514 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q515 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
< RESISTOR >
R501 1-216-821-11 METAL CHIP 1K 5% 1/10W
R502 1-216-821-11 METAL CHIP 1K 5% 1/10W
R503 1-216-842-11 METAL CHIP 56K 5% 1/10W
R504 1-216-842-11 METAL CHIP 56K 5% 1/10W
R507 1-216-821-11 METAL CHIP 1K 5% 1/10W
R508 1-216-821-11 METAL CHIP 1K 5% 1/10W
R509 1-216-833-11 METAL CHIP 10K 5% 1/10W
R510 1-216-839-11 METAL CHIP 33K 5% 1/10W
R511 1-216-821-11 METAL CHIP 1K 5% 1/10W
R512 1-216-842-11 METAL CHIP 56K 5% 1/10W
R513 1-216-842-11 METAL CHIP 56K 5% 1/10W
R514 1-216-821-11 METAL CHIP 1K 5% 1/10W
R515 1-216-821-11 METAL CHIP 1K 5% 1/10W
R516 1-216-835-11 METAL CHIP 15K 5% 1/10W
R517 1-216-835-11 METAL CHIP 15K 5% 1/10W
R518 1-216-841-11 METAL CHIP 47K 5% 1/10W
R519 1-216-841-11 METAL CHIP 47K 5% 1/10W
R520 1-260-076-21 CARBON 10 5% 1/2W
R521 1-260-076-21 CARBON 10 5% 1/2W
R522 1-217-151-00 METAL 0.22 10% 2W
R523 1-217-151-00 METAL 0.22 10% 2W
R524 1-216-162-00 RES-CHIP 33 5% 1/8W
R525 1-216-854-11 METAL CHIP 560K 5% 1/10W
R526 1-216-813-11 METAL CHIP 220 5% 1/10W
R527 1-216-841-11 METAL CHIP 47K 5% 1/10W
R528 1-216-845-11 METAL CHIP 100K 5% 1/10W
R529 1-216-842-11 METAL CHIP 56K 5% 1/10W
R530 1-216-845-11 METAL CHIP 100K 5% 1/10W
R531 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R532 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R533 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R534 1-216-841-11 METAL CHIP 47K 5% 1/10W
R535 1-216-830-11 RES-CHIP 5.6K 5% 1/10W
R536 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R537 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R538 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R539 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R540 1-216-833-11 METAL CHIP 10K 5% 1/10W
R543 1-216-837-11 METAL CHIP 22K 5% 1/10W
R544 1-216-842-11 METAL CHIP 56K 5% 1/10W
R545 1-216-841-11 METAL CHIP 47K 5% 1/10W
R546 1-216-839-11 METAL CHIP 33K 5% 1/10W
R547 1-216-833-11 METAL CHIP 10K 5% 1/10W
R548 1-216-174-00 RES-CHIP 100 5% 1/8W
R549 1-216-174-00 RES-CHIP 100 5% 1/8W
R550 1-260-076-21 CARBON 10 5% 1/2W
R551 1-260-076-21 CARBON 10 5% 1/2W
< RELAY >
RY501 1-755-373-11 RELAY
************************************************************
1-689-250-11 PWR TRANS BOARD
*****************
< CAPACITOR >
C902 1-164-159-21 CERAMIC 0.1uF 50V
C903 1-126-969-11 ELECT 220uF 20.00% 50V
< CONNECTOR >
* CN902 1-564-519-11 PLUG,CONNECTOR 4P
* CN904 1-564-719-11 PIN,CONNECTOR (SMALL TYPE) 3P
* CN907 1-564-524-11 PLUG,CONNECTOR 9P
< DIODE >
D907 6-500-522-21 DIODE 10EDB40-TB3
< FUSIBLE >
0 FR903 1-217-639-00 FUSIBLE 2.2 5% 1/4W
< RESISTOR >
0 R901 1-219-237-91 SOLID 3.3M 20% 1/2W
(US,CND)
************************************************************
1-686-726-12 ROLLER MOTOR BOARD
********************
************************************************************
1-686-723-12 SENSOR BOARD
*************
< IC >
IC751 8-749-017-45 SENSOR,PHONT RPR-220C1N
(DISC INSERT DETECT SENSOR)
************************************************************
1-689-248-12 SENSOR (FAN) BOARD
******************
< THERMISTOR >
TH501 1-807-796-11 THERMISTOR
************************************************************
ST ENCODER BOARD
*****************
************************************************************
PWR AMP PWR TRANS
SENSOR
ROLLER MOTOR
SENSOR (FAN)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
