20
HCD-M10
3-15. CAM (CDM55), LOADING BOARD
3-16. BASE UNIT (BU-K4BD43)
4
Belt (CDM55)
6
Pulley (LDG)
9
Gear (A)
8
Gear (B)
7
Roller
2
Push the claw in the
direction of the arrow
C
.
q;
Cam (CDM55)
3
Pull out the tray.
qa
Two screws (+BTP2.6X6)
qs
LOADING board
5
Spacer (55)
C
A
B
B
Release the lock
1
Pull out the tray in the direction
of the arrow
A
.
While pushing this claw in the
direction of the arrow
B
, release
the lock.
2
Remove the base unit (BU-K4BD43)
in the direction of the arrow
A
.
3
Chassis (F)
A
1
Floating screw (+PTPWHM2.6)
To Next Page
