7-5. MD MECHANISM DECK SECTION-1 (MDM-7B4M)
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
308
307
306
302
301
320
307
302
311
310
309
313
314
315
316
319
318
317
305
303
304
not supplied
not supplied
#6
not
supplied
312
* 301 4-996-267-01 BASE (BU-D)
302 4-231-319-01 SCREW (2X6) CZN, +B (P) TRI
303 4-226-994-01 GUIDE (L)
304 A-4735-075-B HOLDER ASSY
305 X-4952-665-1 SPRING (SHT) ASSY, LEAF
306 4-227-002-01 GEAR, PULLEY
307 3-372-761-01 SCREW (M1.7), TAPPING
308 4-227-025-01 BELT (LOADING)
309 A-468-063-8A LOCK (HOLDER)
310 4-229-533-02 SPRING (STOPPER), TORSION
311 4-231-118-01 SPRING (HOLDER), TENSION
312 A-4680-638-B RETAINER COMPLETE ASSY
313 4-226-995-01 SLIDER (EJ)
314 4-227-013-01 SPRING (EJ), TENSION
315 4-226-996-01 LIMITTER (EJ)
316 4-226-997-04 SLIDER
317 4-226-998-01 LEVER (CHG)
318 4-227-007-01 GEAR (SB)
319 4-227-006-01 GEAR (SA)
320 4-226-999-01 LEVER (HEAD)
#6 7-685-850-04 SCREW +BVTT 2X3 (S)
