Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 105 —
A-4426-574-A POWER AMP BOARD, COMPLETE (US)
***************************
A-4426-575-A POWER AMP BOARD, COMPLETE (CND)
***************************
A-4426-576-A POWER AMP BOARD, COMPLETE (AUS)
***************************
< CAPACITOR >
C601 1-124-584-00 ELECT 100uF 20% 10V
C602 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C603 1-126-157-11 ELECT 10uF 20% 16V
C604 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C605 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C801 1-128-582-11 ELECT 10uF 20% 100V
C802 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C803 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C804 1-126-967-11 ELECT 47uF 20% 50V
C806 1-126-967-11 ELECT 47uF 20% 50V
C807 1-128-560-11 ELECT 22uF 20% 100V
C809 1-128-560-11 ELECT 22uF 20% 100V
C810 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C811 1-136-163-00 FILM 0.068uF 5% 50V
C812 1-136-163-00 FILM 0.068uF 5% 50V
C821 1-106-220-00 MYLAR 0.1uF 5% 100V
C822 1-109-973-11 ELECT(BLOCK) 4700uF 20% 63V
(US,CND)
C822 1-117-750-11 ELECT 3300uF 20% 63V
(AUS)
C823 1-126-925-11 ELECT 470uF 20% 10V
C851 1-128-582-11 ELECT 10uF 20% 100V
C852 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C853 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C854 1-126-967-11 ELECT 47uF 20% 50V
C856 1-126-967-11 ELECT 47uF 20% 50V
C857 1-128-560-11 ELECT 22uF 20% 100V
C861 1-136-163-00 FILM 0.068uF 5% 50V
C862 1-136-163-00 FILM 0.068uF 5% 50V
C871 1-106-220-00 MYLAR 0.1uF 5% 100V
C872 1-109-973-11 ELECT(BLOCK) 4700uF 20% 63V
(US,CND)
C872 1-117-750-11 ELECT 3300uF 20% 63V
(AUS)
< CONNECTOR >
* CN803 1-564-511-11 PLUG, CONNECTOR 8P
< DIODE >
D628 8-719-074-81 DIODE MAA3864X-J300K
D801 8-719-988-61 DIODE 1SS355TE-17
D811 8-719-988-61 DIODE 1SS355TE-17
D812 8-719-988-61 DIODE 1SS355TE-17
D813 8-719-988-61 DIODE 1SS355TE-17
D821 8-719-510-68 DIODE D5SBA204101
D851 8-719-988-61 DIODE 1SS355TE-17
< INDICATOR TUBE, FLUORESCENT >
FL601 1-517-773-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC801 8-749-922-65 IC STK4221MK2 (US)
IC801 8-749-921-04 IC STK4211MK2 (CND)
IC801 8-749-921-68 IC STK4231MK2 (AUS)
< TRANSISTOR >
Q801 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q811 8-729-900-36 TRANSISTOR BA1F4M-TP
Q812 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q851 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
< RESISTOR >
R631 1-216-029-00 METAL CHIP 150 5% 1/10W
R632 1-216-025-91 RES,CHIP 100 5% 1/10W
R647 1-216-033-00 METAL CHIP 220 5% 1/10W
R656 1-216-033-00 METAL CHIP 220 5% 1/10W
R657 1-216-035-00 METAL CHIP 270 5% 1/10W
R658 1-216-039-00 METAL CHIP 390 5% 1/10W
R659 1-216-041-00 METAL CHIP 470 5% 1/10W
R801 1-216-049-91 RES,CHIP 1K 5% 1/10W
R802 1-216-089-91 RES,CHIP 47K 5% 1/10W
R803 1-216-041-00 METAL CHIP 470 5% 1/10W
R804 1-216-089-91 RES,CHIP 47K 5% 1/10W
R805 1-249-425-11 CARBON 4.7K 5% 1/4W F
R806 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R807 1-212-881-11 FUSIBLE 100 5% 1/4W F
R808 1-220-893-11 METAL 0.22 10% 5W
R809 1-260-076-11 CARBON 10 5% 1/2W
R811 1-216-049-91 RES,CHIP 1K 5% 1/10W
R812 1-216-077-00 METAL CHIP 15K 5% 1/10W
R813 1-216-097-91 RES,CHIP 100K 5% 1/10W
R815 1-247-843-11 CARBON 3.3K 5% 1/4W
R816 1-247-843-11 CARBON 3.3K 5% 1/4W
R821 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R822 1-216-109-00 METAL CHIP 330K 5% 1/10W
R823 1-216-073-00 METAL CHIP 10K 5% 1/10W
R824 1-216-073-00 METAL CHIP 10K 5% 1/10W
R825 1-216-097-91 RES,CHIP 100K 5% 1/10W
R826 1-216-097-91 RES,CHIP 100K 5% 1/10W
R827 1-216-097-91 RES,CHIP 100K 5% 1/10W
R851 1-216-049-91 RES,CHIP 1K 5% 1/10W
R852 1-216-089-91 RES,CHIP 47K 5% 1/10W
R853 1-216-041-00 METAL CHIP 470 5% 1/10W
R854 1-216-089-91 RES,CHIP 47K 5% 1/10W
R855 1-249-425-11 CARBON 4.7K 5% 1/4W F
R856 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R857 1-212-881-11 FUSIBLE 100 5% 1/4W F
R858 1-220-893-11 METAL 0.22 10% 5W
R859 1-260-076-11 CARBON 10 5% 1/2W
R861 1-216-049-91 RES,CHIP 1K 5% 1/10W
R862 1-216-077-00 METAL CHIP 15K 5% 1/10W
R863 1-216-097-91 RES,CHIP 100K 5% 1/10W
< THERMISTOR >
TH811 1-807-796-11 THERMISTOR
************************************************************
POWER AMP
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
