Sony HCD-MC3AV - Miscellaneous Parts Lists

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 106 —
* A-4407-823-A SURR BOARD, COMPLETE
*********************
< CAPACITOR >
C201 1-136-165-00 FILM 0.1uF 5% 50V
C202 1-136-165-00 FILM 0.1uF 5% 50V
C203 1-126-964-11 ELECT 10uF 20% 50V
C204 1-126-964-11 ELECT 10uF 20% 50V
C205 1-126-964-11 ELECT 10uF 20% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-934-11 ELECT 220uF 20% 10V
C209 1-164-159-21 CERAMIC 0.1uF 50V
C210 1-126-961-11 ELECT 2.2uF 20% 50V
C211 1-126-934-11 ELECT 220uF 20% 10V
C212 1-126-961-11 ELECT 2.2uF 20% 50V
C213 1-126-964-11 ELECT 10uF 20% 50V
C214 1-126-964-11 ELECT 10uF 20% 50V
C215 1-126-934-11 ELECT 220uF 20% 10V
C216 1-136-165-00 FILM 0.1uF 5% 50V
C217 1-136-165-00 FILM 0.1uF 5% 50V
C218 1-126-160-11 ELECT 1uF 20% 50V
C219 1-126-961-11 ELECT 2.2uF 20% 50V
C220 1-126-160-11 ELECT 1uF 20% 50V
C221 1-136-165-00 FILM 0.1uF 5% 50V
C222 1-126-961-11 ELECT 2.2uF 20% 50V
C223 1-124-252-00 ELECT 0.33uF 20% 50V
C224 1-126-959-11 ELECT 0.47uF 20% 50V
C225 1-136-164-00 FILM 0.082uF 5% 50V
C226 1-130-477-00 MYLAR 0.0033uF 5% 50V
C227 1-136-164-00 FILM 0.082uF 5% 50V
C228 1-164-159-21 CERAMIC 0.1uF 50V
C229 1-126-934-11 ELECT 220uF 20% 10V
C230 1-130-469-00 MYLAR 680PF 5% 50V
C231 1-136-161-00 FILM 0.047uF 5% 50V
C232 1-136-157-00 FILM 0.022uF 5% 50V
C233 1-136-173-00 FILM 0.47uF 5% 50V
C234 1-126-967-11 ELECT 47uF 20% 16V
C235 1-126-961-11 ELECT 2.2uF 20% 50V
C236 1-126-961-11 ELECT 2.2uF 20% 50V
C237 1-136-165-00 FILM 0.1uF 5% 50V
C238 1-136-165-00 FILM 0.1uF 5% 50V
C239 1-126-959-11 ELECT 0.47uF 20% 50V
C240 1-126-963-11 ELECT 4.7uF 20% 50V
C241 1-126-959-11 ELECT 0.47uF 20% 50V
C242 1-126-963-11 ELECT 4.7uF 20% 50V
C243 1-136-167-00 FILM 0.15uF 5% 50V
C244 1-126-962-11 ELECT 3.3uF 20% 50V
C245 1-136-167-00 FILM 0.15uF 5% 50V
C246 1-136-167-00 FILM 0.15uF 5% 50V
C247 1-126-962-11 ELECT 3.3uF 20% 50V
C248 1-136-167-00 FILM 0.15uF 5% 50V
C249 1-126-963-11 ELECT 4.7uF 20% 50V
C250 1-126-959-11 ELECT 0.47uF 20% 50V
C251 1-126-963-11 ELECT 4.7uF 20% 50V
C252 1-126-959-11 ELECT 0.47uF 20% 50V
C253 1-164-159-21 CERAMIC 0.1uF 50V
C254 1-124-903-11 ELECT 1uF 20% 50V
C255 1-124-903-11 ELECT 1uF 20% 50V
C256 1-124-903-11 ELECT 1uF 20% 50V
C298 1-126-935-11 ELECT 470uF 20% 16V
C299 1-137-198-11 CERAMIC 1uF 5% 50V
C831 1-126-963-11 ELECT 4.7uF 20% 50V
C832 1-162-292-31 CERAMIC 680PF 10% 50V
C833 1-162-286-21 CERAMIC 220PF 10% 50V
C834 1-126-967-11 ELECT 47uF 20% 50V
C836 1-126-967-11 ELECT 47uF 20% 50V
C837 1-126-968-11 ELECT 100uF 20% 50V
C839 1-126-965-11 ELECT 22uF 20% 50V
C841 1-136-163-00 FILM 0.068uF 5% 50V
C842 1-136-163-00 FILM 0.068uF 5% 50V
C845 1-104-664-11 ELECT 47uF 20% 25V
C846 1-162-294-31 CERAMIC 0.001uF 10% 50V
C881 1-126-963-11 ELECT 4.7uF 20% 50V
C882 1-162-292-31 CERAMIC 680PF 10% 50V
C883 1-162-286-21 CERAMIC 220PF 10% 50V
C884 1-126-967-11 ELECT 47uF 20% 50V
C886 1-126-967-11 ELECT 47uF 20% 50V
C887 1-126-968-11 ELECT 100uF 20% 50V
C891 1-136-163-00 FILM 0.068uF 5% 50V
C892 1-136-163-00 FILM 0.068uF 5% 50V
< CONNECTOR >
* CN201 1-568-935-11 PIN, CONNECTOR 8P
* CN202 1-568-954-11 PIN, CONNECTOR 5P
* CN831 1-564-509-11 PLUG, CONNECTOR 6P
* CN832 1-564-507-11 PLUG, CONNECTOR 4P
< DIODE >
D863 8-719-991-33 DIODE 1SS133T-77
< IC >
IC201 8-759-526-39 IC LV1041M
IC831 8-749-900-96 IC STK-4142MK2
< COIL >
L241 1-410-521-11 INDUCTOR 100uH
< TRANSISTOR >
Q291 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q292 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q831 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q834 8-729-119-78 TRANSISTOR 2SC403SP-51
Q881 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R201 1-247-863-91 CARBON 22K 5% 1/4W
R202 1-247-863-91 CARBON 22K 5% 1/4W
R203 1-249-436-11 CARBON 39K 5% 1/4W
R204 1-247-903-00 CARBON 1M 5% 1/4W
R205 1-247-815-91 CARBON 220 5% 1/4W F
R206 1-247-807-31 CARBON 100 5% 1/4W
R207 1-247-807-31 CARBON 100 5% 1/4W
R208 1-247-807-31 CARBON 100 5% 1/4W
R209 1-247-807-31 CARBON 100 5% 1/4W
R257 1-249-417-11 CARBON 1K 5% 1/4W F
SURR
