Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 107 —
R258 1-249-417-11 CARBON 1K 5% 1/4W F
R259 1-249-437-11 CARBON 47K 5% 1/4W
R260 1-249-437-11 CARBON 47K 5% 1/4W
R261 1-249-429-11 CARBON 10K 5% 1/4W
R262 1-249-429-11 CARBON 10K 5% 1/4W
R263 1-249-437-11 CARBON 47K 5% 1/4W
R264 1-249-437-11 CARBON 47K 5% 1/4W
R831 1-249-417-11 CARBON 1K 5% 1/4WF
R832 1-249-437-11 CARBON 47K 5% 1/4W
R833 1-249-413-11 CARBON 470 5% 1/4W F
R834 1-249-437-11 CARBON 47K 5% 1/4W
R835 1-249-425-11 CARBON 4.7K 5% 1/4W F
R836 1-249-425-11 CARBON 4.7K 5% 1/4W F
R837 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R838 1-220-755-11 METAL 0.22 10% 2W
R839 1-247-791-91 CARBON 22 5% 1/4W
R840 1-247-791-91 CARBON 22 5% 1/4W
R841 1-249-441-11 CARBON 100K 5% 1/4W
R842 1-249-441-11 CARBON 100K 5% 1/4W
R843 1-249-441-11 CARBON 100K 5% 1/4W
R844 1-249-421-11 CARBON 2.2K 5% 1/4W F
R845 1-249-421-11 CARBON 2.2K 5% 1/4W F
R846 1-249-421-11 CARBON 2.2K 5% 1/4W F
R847 1-249-421-11 CARBON 2.2K 5% 1/4W F
R849 1-249-425-11 CARBON 4.7K 5% 1/4W F
R850 1-249-425-11 CARBON 4.7K 5% 1/4W F
R881 1-249-417-11 CARBON 1K 5% 1/4W F
R882 1-249-437-11 CARBON 47K 5% 1/4W
R883 1-249-413-11 CARBON 470 5% 1/4W F
R884 1-249-437-11 CARBON 47K 5% 1/4W
R885 1-249-425-11 CARBON 4.7K 5% 1/4W F
R886 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R887 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R888 1-220-755-11 METAL 0.22 10% 2W
R889 1-247-791-91 CARBON 22 5% 1/4W
R890 1-247-791-91 CARBON 22 5% 1/4W
R891 1-249-441-11 CARBON 100K 5% 1/4W
R892 1-249-441-11 CARBON 100K 5% 1/4W
R893 1-249-441-11 CARBON 100K 5% 1/4W
R894 1-249-429-11 CARBON 10K 5% 1/4W
R895 1-249-427-11 CARBON 6.8K 5% 1/4W F
R896 1-247-862-11 CARBON 20K 5% 1/4W
R899 1-249-425-11 CARBON 4.7K 5% 1/4W F
R900 1-249-425-11 CARBON 4.7K 5% 1/4W F
< VIBRATOR >
X201 1-579-125-11 VIBRATOR, CERAMIC (8MHz)
************************************************************
1-674-312-11 SW/POWER BOARD
****************
< LED >
D617 8-719-074-80 LED MVR3864X-J300K (REC)
D618 8-719-074-82 LED MAY3864X-J300K (PAUSE)
D627 8-719-074-80 LED MVR3864X-J300K (PRO LOGIC)
< SWITCH >
S624 1-762-875-21 SWITCH, KEYBOARD(PRO LOGIC)
S625 1-762-875-21 SWITCH, KEYBOARD(POWER)
S626 1-762-875-21 SWITCH, KEYBOARD(HI-SPEED DUBBING)
S627 1-762-875-21 SWITCH, KEYBOARD(CD SYNCHRO)
S628 1-762-875-21 SWITCH, KEYBOARD(REC)
S629 1-762-875-21 SWITCH, KEYBOARD(PAUSE)
************************************************************
* 1-663-971-11 TABLE SENSOR BOARD
*******************
< CONNECTOR >
* CN51 1-568-944-11 PIN, CONNECTOR 6P
CN52 1-506-481-11 PIN, CONNECTOR 2P
< IC >
IC51 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
IC52 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
IC53 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R51 1-249-416-11 CARBON 820 5% 1/4W F
R52 1-249-416-11 CARBON 820 5% 1/4W F
R53 1-249-416-11 CARBON 820 5% 1/4W F
************************************************************
1-674-313-11 TRANS BOARD
************
< CONNECTOR >
CN991 1-564-321-00 PIN, CONNECTOR 2P
* CN992 1-564-518-11 PLUG, CONNECTOR 3P
* CN993 1-564-522-11 PLUG, CONNECTOR 7P
< FUSE >
! F992 1-533-310-11 FUSE GRASS CYLINDRICAL (DIA.5)
6.3A/125V (US,CND)
! F993 1-532-506-51 FUSE 6.3A/250V (AUS)
! F994 1-532-506-51 FUSE 6.3A/250V (AUS)
< RESISTOR >
! R991 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R992 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R993 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R994 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R995 1-202-725-00 SOLID 3.3M 10% 1/2W
< TRANSFORMER >
! T991 1-431-840-21 TRANSFORMER, POWER (US)
! T991 1-431-841-21 TRANSFORMER, POWER (CND)
! T991 1-431-842-21 TRANSFORMER, POWER (AUS)
************************************************************
SURR
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
SW/POWER TABLE SENSOR TRANS
