Sony HCD-MC3AV - Page 82

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 108 —
MISCELLANEOUS
***************
5 A-4424-239-A TUNER UNIT (US, CND)
5 A-4424-240-A TUNER UNIT (AUS)
6 1-769-972-11 WIRE (FLAT TYPE) (13 CORE)
8 1-765-332-11 WIRE (FLAT TYPE) (15 CORE)
9 1-773-055-11 WIRE (FLAT TYPE) (17 CORE)
70 1-769-920-11 WIRE (FLAT TYPE) (9 CORE)
110 1-782-558-21 WIRE (FLAT TYPE) (16 CORE)
111 1-782-559-21 WIRE (FLAT TYPE) (9 CORE)
! 114 1-783-531-11 CORD, POWER (US,CND)
! 114 1-775-790-31 CORD, POWER (AUS)
322 1-777-874-11 WIRE (FLAT TYPE) (16 CORE)
! 401 8-848-379-31 OPTICAL PICK-UP KSS-213BFN/C2NP
FAN101 1-698-792-11 FAN, DC
HP101 A-2056-681-B DECK (A) ASSY, HEAD(230AWR2)
HP101 A-2056-683-B DECK (A) ASSY, HEAD(230PWR2)
HRPE10 A-2056-682-B DECK (B) ASSY, HEAD(230AWR2)
HRPE101A-2056-684-B DECK (B) ASSY, HEAD(230PWR2)
M1 A-2004-628-A MOTOR ASSY, CAPSTAN
M61 X-4948-434-1 MOTOR ASSY (LOADING)
M62 X-4948-434-1 MOTOR ASSY (TABLE)
M101 X-2646-110-1 T, T CHASSIS ASSY (MG) (F) (SPINDLE)
M102 X-2625-769-1 MOTOR GEAR ASSY (MB) (RP) (SLED)
! T991 1-431-840-21 TRANSFORMER, POWER (US)
! T991 1-431-841-21 TRANSFORMER, POWER (CND)
! T991 1-431-842-21 TRANSFORMER, POWER (AUS)
************************************************************
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3 × 8 TYPE2 N-S
#2 7-685-872-09 SCREW +BVTT 3 × 8 (S)
#3 7-685-871-01 SCREW +BVTT 3 × 6 (S)
#4 7-685-650-79 SCREW +BVTP 3 × 16 TYPE2 IT-3
#5 7-685-873-09 SCREW +BVTT 3 × 10 (S)
#6 7-685-875-09 SCREW +BVTT 3 × 14 (S)
#8 7-685-852-04 SCREW +BVTT 2 × 5 (S)
#9 7-685-851-04 SCREW +BVTT 2 × 4 (S)
#10 7-685-534-19 SCREW +BTP 2.6 × 8 TYPE2 N-S
#11 7-628-254-15 SCREW +PS 2.6 × 6
#12 7-628-254-50 SCREW +PS 2.6 × 16
#14 7-685-132-19 SCREW +BTP 2.6 × 5 TYPE2 N-S
#15 7-685-107-11 SCREW +P 2 × 12 TYPE2 NON-SLIT
#16 7-685-535-19 SCREW +BTP 2.6 × 10 TYPE2 N-S
#17 7-685-134-19 SCREW (+ PTPWH) (2.6 × 8)
#18 7-685-103-19 +PTPWH (2 × 5)
#19 7-627-553-17 SCREW,PRECISION +P 2 × 2
#20 7-685-902-11 SCREW +PWH 2.6 × 6
HCD-MC3AV
Sony Corporation
Home Audio Company
9-928-900-11
99E167042-1
Printed in Singapore ©1999.5
Published by Quality Assurance Dept.
