Sony HCD-MD5 - Front Panel Facilities; Rear Panel Facilities

– 5 –
SECTION 2
GENERAL
This section is extracted
from instruction manual.
Front Panel
Index to Parts and Controls
1 TUNER/BAND button 2 PLAY MODE/TUNING MODE button 3 REPEAT/STEREO/MONO button 4 1/ALL DISCS button 5 DISPLAY button 6 TIMER SET button 7 TIMER SELECT button 8 EDIT/NO button 9 MULTI JOG control 0 ENTER/YES button !¡ º/‚ (fast backward/fast forward)
←/→ CUSOR button
!™ VOLUME control !£ CHARACTER button !¢ PRESET EQ button
!∞ SYSTEM POWER switch !§ FUNCTION button !¶ MD control button
· (MD play) button ∏ (MD pause) button π (MD stop) button § (MD EJECT) button MD slot
!• DBFB button !ª GROOVE button @º CD SYNC button @¡ r REC button @™ PHONES jack @£ LOOP button @¢ EX-CHANGE button @∞ DISC SKIP button @§ CD control button
· (CD play) button ∏ (CD pause) button π (CD stop) button § (CD EJECT) button
@¶ DISC 1-3 buttons @• DISC TRAY

123
5
67
4
6
EXCEPT AEP,
German, UK mode
l
AEP, German, UK model
8
Rear Panel
1 CD OPTICAL DIGITAL OUT jack 2 SPEAKER connectors 3 AU BUS connector 4 TAPE input/output jack 5 VIDEO GAME/VCR connectors 6 Aerial terminals 7 SIGNAL Ground terminal 8 VOLTAGE SELECTOR
(Malaysia, singapore, Saudi Arabia, Hong Kong, Tourist model)
