Sony HCD-MD5 - Electrical Parts List

– 132 –
SECTION 8
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used on
the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
When indicating parts by reference
number, please include the board.
AMPLIFIER
• Abbreviation
G : German EA : Sausi Arabia
HK : Hong Kong SP : Singapore
MY: Malaysia JE : Tourist
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* A-4390-876-A AMPLIFIER BOARD, COMPLETE (AEP, G)
* A-4390-880-A AMPLIFIER BOARD, COMPLETE (UK)
* A-4392-032-A AMPLIFIER BOARD, COMPLETE (MY, SP)
**************************
< CAPACITOR >
C901 1-126-963-11 ELECT 4.7uF 20% 50V
C902 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP, G, UK)
C902 1-162-290-31 CERAMIC 470PF 10% 50V
(MY, SP, EA, HK, JE)
C903 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP, G, UK)
C903 1-162-286-31 CERAMIC 220PF 10% 50V
(MY, SP, EA, HK, JE)
C904 1-126-967-11 ELECT 47uF 20% 50V
C905 1-126-967-11 ELECT 47uF 20% 50V
C906 1-136-163-00 FILM 0.068uF 5% 50V
C907 1-136-163-00 FILM 0.068uF 5% 50V
C921 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, G, UK)
C922 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, G, UK)
C932 1-126-967-11 ELECT 47uF 20% 50V
C933 1-136-161-00 FILM 0.047uF 5% 50V
C934 1-126-968-11 ELECT 100uF 20% 50V
C937 1-126-965-11 ELECT 22uF 20% 50V
C938 1-126-934-11 ELECT 220uF 20% 16V
C940 1-126-967-11 ELECT 47uF 20% 50V
C950 1-136-161-00 FILM 0.047uF 5% 50V
C951 1-126-963-11 ELECT 4.7uF 20% 50V
C952 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP, G, UK)
C952 1-162-290-31 CERAMIC 470PF 10% 50V
(MY, SP, EA, HK, JE)
C953 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP, G, UK)
C953 1-162-286-31 CERAMIC 220PF 10% 50V
(MY, SP, EA, HK, JE)
C954 1-126-967-11 ELECT 47uF 20% 50V
C955 1-126-967-11 ELECT 47uF 20% 50V
C956 1-136-163-00 FILM 0.068uF 5% 50V
C957 1-136-163-00 FILM 0.068uF 5% 50V
C971 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, G, UK)
C972 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, G, UK)
C982 1-126-923-11 ELECT 220uF 20% 10V
C983 1-164-159-11 CERAMIC 0.1uF 50V
C984 1-124-925-11 ELECT 2.2uF 20% 100V
C985 1-126-933-11 ELECT 100uF 20% 10V
C986 1-124-261-00 ELECT 10uF 20% 50V
C987 1-126-923-11 ELECT 220uF 20% 10V
C7006 1-126-961-11 ELECT 2.2uF 20% 50V
(UK)
< CONNECTOR >
CN901 1-778-452-21 CONNECTOR, BOARD TO BOARD 13P
* CN903 1-565-561-11 PIN, CONNECTOR 3P
CN906 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
< DIODE >
D903 8-719-987-63 DIODE 1N4148M
D931 8-719-987-63 DIODE 1N4148M
D953 8-719-987-63 DIODE 1N4148M
D981 8-719-987-63 DIODE 1N4148M
D982 8-719-987-63 DIODE 1N4148M
D983 8-719-987-63 DIODE 1N4148M
< IC >
IC901 8-749-920-09 IC STK-4152MK2K
IC981 8-759-111-68 IC UPC1237HA
< COIL >
L921 1-420-872-00 COIL, AIR-CORE (AEP, G, UK)
L971 1-420-872-00 COIL, AIR-CORE (AEP, G, UK)
