– 140 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R646 1-550-907-21 BEAD, FERRITE (CHIP)
< VIBRATOR >
X201 1-760-493-11 VIBRATOR, CERAMIC (CHIP TYPE) (8MHz)
X203 1-760-841-11 VIBRATOR, CRYSTAL (45MHz)
************************************************************
* 1-662-211-11 HEADPHONE BOARD
****************
< CONNECTOR >
CN904 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
< JACK >
J901 1-770-225-11 JACK (LARGE TYPE) (PHONES)
************************************************************
* A-4390-874-A MAIN BOARD, COMPLETE (AEP, G)
* A-4390-878-A MAIN BOARD, COMPLETE (UK)
* A-4392-030-A MAIN BOARD, COMPLETE (MY, SP)
* A-4390-882-A MAIN BOARD, COMPLETE (EA, HK, JE)
*********************
< CAPACITOR >
C103 1-136-169-00 FILM 0.22uF 5% 50V
C104 1-136-169-00 FILM 0.22uF 5% 50V
C105 1-136-163-00 FILM 0.068uF 5% 50V
C106 1-136-163-00 FILM 0.068uF 5% 50V
C107 1-136-156-00 FILM 0.018uF 5% 50V
C108 1-136-156-00 FILM 0.018uF 5% 50V
C109 1-102-126-00 CERAMIC 0.0056uF 10% 50V
C110 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C111 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C112 1-126-963-11 ELECT 4.7uF 20% 50V
C113 1-126-963-11 ELECT 4.7uF 20% 50V
C114 1-136-166-00 FILM 0.12uF 5% 50V
C115 1-136-166-00 FILM 0.12uF 5% 50V
C116 1-126-961-11 ELECT 2.2uF 20% 50V
C117 1-162-306-11 CERAMIC 0.01uF 30% 16V
C118 1-124-907-11 ELECT 10uF 20% 50V
C119 1-126-163-11 ELECT 4.7uF 20% 50V
C134 1-124-907-11 ELECT 10uF 20% 50V
C135 1-162-306-11 CERAMIC 0.01uF 30% 16V
C153 1-136-169-00 FILM 0.22uF 5% 50V
C154 1-136-169-00 FILM 0.22uF 5% 50V
C155 1-136-163-00 FILM 0.068uF 5% 50V
C156 1-136-163-00 FILM 0.068uF 5% 50V
C157 1-136-156-00 FILM 0.018uF 5% 50V
C158 1-136-156-00 FILM 0.018uF 5% 50V
C159 1-102-126-00 CERAMIC 0.0056uF 10% 50V
C160 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C161 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C162 1-126-963-11 ELECT 4.7uF 20% 50V
C163 1-126-963-11 ELECT 4.7uF 20% 50V
C164 1-136-166-00 FILM 0.12uF 5% 50V
C165 1-136-166-00 FILM 0.12uF 5% 50V
C166 1-126-961-11 ELECT 2.2uF 20% 50V
C167 1-124-907-11 ELECT 10uF 20% 50V
C168 1-162-306-11 CERAMIC 0.01uF 30% 16V
C169 1-126-963-11 ELECT 4.7uF 20% 50V
C702 1-126-163-11 ELECT 4.7uF 20% 50V
C703 1-126-963-11 ELECT 4.7uF 20% 50V
C715 1-162-282-31 CERAMIC 100PF 10% 50V
C717 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP, G, UK)
C721 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C722 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C723 1-126-163-11 ELECT 4.7uF 20% 50V
C724 1-126-157-11 ELECT 10uF 20% 16V
C726 1-124-907-11 ELECT 10uF 20% 50V
C733 1-124-907-11 ELECT 10uF 20% 50V
C734 1-124-907-11 ELECT 10uF 20% 50V
C752 1-126-963-11 ELECT 4.7uF 20% 50V
C753 1-126-963-11 ELECT 4.7uF 20% 50V
C755 1-162-282-31 CERAMIC 100PF 10% 50V
C767 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP, G, UK)
C771 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C772 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C773 1-126-163-11 ELECT 4.7uF 20% 50V
C774 1-126-157-11 ELECT 10uF 20% 16V
C776 1-126-157-11 ELECT 10uF 20% 16V
C799 1-162-282-31 CERAMIC 100PF 10% 50V
C1000 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP, G, UK)
C1001 1-162-306-11 CERAMIC 0.01uF 30% 16V
HEADPHONE MAIN
