Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 68 —
R516 1-260-076-11 CARBON 10 5% 1/2W
R517 1-260-076-11 CARBON 10 5% 1/2W
R521 1-249-389-11 CARBON 4.7 5% 1/4W F
R522 1-249-389-11 CARBON 4.7 5% 1/4W F
R525 1-260-083-11 CARBON 47 5% 1/2W
R526 1-260-083-11 CARBON 47 5% 1/2W
R527 1-249-393-11 CARBON 10 5% 1/4W F
R551 1-208-601-11 REGISTER 0.1 10% 2W F
R552 1-208-601-11 REGISTER 0.1 10% 2W F
R553 1-247-879-11 CARBON 100K 5% 1/4W
R554 1-247-879-11 CARBON 100K 5% 1/4W
R555 1-247-839-11 CARBON 2.2K 5% 1/4W
R556 1-247-839-11 CARBON 2.2K 5% 1/4W
R557 1-249-431-11 CARBON 15K 5% 1/4W
R558 1-249-431-11 CARBON 15K 5% 1/4W
R559 1-247-839-11 CARBON 2.2K 5% 1/4W
R560 1-249-430-11 CARBON 12K 5% 1/4W
R561 1-249-430-11 CARBON 12K 5% 1/4W
R562 1-247-871-11 CARBON 47K 5% 1/4W
R563 1-247-855-11 CARBON 10K 5% 1/4W
R564 1-247-879-11 CARBON 100K 5% 1/4W
R565 1-247-847-11 CARBON 4.7K 5% 1/4W
R566 1-249-417-11 CARBON 1K 5% 1/4W F
R567 1-249-438-11 CARBON 56K 5% 1/4W
R583 1-249-439-11 CARBON 68K 5% 1/4W
R584 1-247-847-11 CARBON 4.7K 5% 1/4W
R585 1-247-839-11 CARBON 2.2K 5% 1/4W
R586 1-249-431-11 CARBON 15K 5% 1/4W
R587 1-249-432-11 CARBON 18K 5% 1/4W
R588 1-249-438-11 CARBON 56K 5% 1/4W
R589 1-249-434-11 CARBON 27K 5% 1/4W
R590 1-249-431-11 CARBON 15K 5% 1/4W
R591 1-247-847-11 CARBON 4.7K 5% 1/4W
< RELAY >
RL501 1-515-921-11 RELAY (12V)
< METAL RES >
SFR101 1-228-995-00 RES, ADJ, METAL 22K
SFR201 1-228-993-00 RES, ADJ, METAL 4.7K
< TRIMMER >
TC101 1-141-304-21 CAP, TRIMMER 10PF
< TRANSFORMER >
T101 1-429-553-11 TRANSFORMER, FM IFT
T102 1-429-554-11 TRANSFORMER, AM IFT
< VIBRATOR >
X101 1-579-585-11 VIBRATOR, CRYSTAL 7.2MHz
************************************************************
* 1-670-801-11 MOTOR BOARD
*************
< CAPACITOR >
C01 1-126-963-11 ELECT 4.7uF 20% 50V
C82 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN06 1-568-824-11 SOCKET, CONNECTOR 5P
************************************************************
* 1-639-678-12 MOTOR (6P) (S) BOARD
*******************
< CONNECTOR >
CN1 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
< MOTOR >
M101 X-2625-877-1 MOTOR ASSY (SPINDLE)
M102 X-2625-769-1 MOTOR ASSY (SLED)
< SWITCH >
S1 1-572-085-11 SWITCH, LEAF (LIMIT)
************************************************************
* A-4414-553-A PANEL BOARD, COMPLETE
**********************
* 4-210-348-01 HOLDER, LED
< CAPACITOR >
C601 1-164-159-11 CERAMIC 0.1uF 50V
C602 1-126-933-11 ELECT 100uF 20% 16V
C603 1-126-916-11 ELECT 1000uF 20% 6.3V
C604 1-161-494-00 CERAMIC 0.022uF 25V
C605 1-126-967-11 ELECT 47uF 20% 16V
C606 1-164-159-11 CERAMIC 0.1uF 50V
C607 1-126-961-11 ELECT 2.2uF 20% 50V
C608 1-126-960-11 ELECT 1uF 20% 50V
C609 1-164-159-11 CERAMIC 0.1uF 50V
C610 1-126-967-11 ELECT 47uF 20% 16V
C611 1-161-494-00 CERAMIC 0.022uF 25V
C612 1-162-201-31 CERAMIC 12PF 5% 50V
C613 1-162-201-31 CERAMIC 12PF 5% 50V
C614 1-126-960-11 ELECT 1uF 20% 50V
C615 1-162-282-31 CERAMIC 100PF 10% 50V
C616 1-130-491-00 MYLAR 0.047uF 5% 50V
C617 1-130-491-00 MYLAR 0.047uF 5% 50V
C619 1-130-491-00 MYLAR 0.047uF 5% 50V
C620 1-126-933-11 ELECT 100uF 20% 16V
C621 1-161-494-00 CERAMIC 0.022uF 25V
C623 1-162-294-31 CERAMIC 0.001uF 10% 50V
C624 1-162-294-31 CERAMIC 0.001uF 10% 50V
C625 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
* CN301 1-770-332-11 HOUSING, CONNECTOR (PC BOARD) 17P
CN601 1-568-468-11 SOCKET, CONNECTOR 18P
MAIN MOTOR MOTOR (6P) (S) PANEL
