Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 69 —
< DIODE >
D601 8-719-911-19 DIODE 1SS119-25
D602 8-719-911-19 DIODE 1SS119-25
D603 8-719-911-19 DIODE 1SS119-25
D604 8-719-911-19 DIODE 1SS119-25
D605 8-719-911-19 DIODE 1SS119-25
D606 8-719-911-19 DIODE 1SS119-25
D607 8-719-911-19 DIODE 1SS119-25
D608 8-719-911-19 DIODE 1SS119-25
D609 8-719-911-19 DIODE 1SS119-25
D610 8-719-911-19 DIODE 1SS119-25
D611 8-719-911-19 DIODE 1SS119-25
< FLUORECENT INDICATOR >
FLD601 1-517-761-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 8-759-539-19 IC uPD780205GF-042-3BA
IC602 8-759-275-23 IC BU2092
< COIL >
L601 1-408-096-00 INDUCTOR 470uH
L602 1-408-611-31 INDUCTOR 47uH
< LED >
LED601 8-719-046-80 DIODE SML19416W-TP4
LED602 8-719-044-69 DIODE SEL1910DTP3
< TRANSISTOR >
Q601 8-729-194-57 TRANSISTOR 2SC945-P
Q602 8-729-194-57 TRANSISTOR 2SC945-P
Q603 8-729-194-57 TRANSISTOR 2SC945-P
Q604 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q605 8-729-029-86 TRANSISTOR DTC124ESA
Q606 8-729-029-86 TRANSISTOR DTC124ESA
< RESISTOR >
R601 1-247-871-11 CARBON 47K 5% 1/4W
R602 1-249-417-11 CARBON 1K 5% 1/4W F
R603 1-249-417-11 CARBON 1K 5% 1/4W F
R604 1-247-871-11 CARBON 47K 5% 1/4W
R605 1-247-871-11 CARBON 47K 5% 1/4W
R606 1-249-417-11 CARBON 1K 5% 1/4W F
R607 1-249-431-11 CARBON 15K 5% 1/4W
R608 1-247-871-11 CARBON 47K 5% 1/4W
R609 1-247-855-11 CARBON 10K 5% 1/4W
R610 1-247-855-11 CARBON 10K 5% 1/4W
R611 1-247-855-11 CARBON 10K 5% 1/4W
R612 1-247-855-11 CARBON 10K 5% 1/4W
R613 1-247-855-11 CARBON 10K 5% 1/4W
R614 1-247-855-11 CARBON 10K 5% 1/4W
R615 1-247-855-11 CARBON 10K 5% 1/4W
R616 1-249-418-11 CARBON 1.2K 5% 1/4W F
R617 1-249-420-11 CARBON 1.8K 5% 1/4W F
R618 1-249-418-11 CARBON 1.2K 5% 1/4W F
R619 1-249-420-11 CARBON 1.8K 5% 1/4W F
R620 1-247-841-11 CARBON 2.7K 5% 1/4W
R621 1-249-424-11 CARBON 3.9K 5% 1/4W F
R622 1-249-427-11 CARBON 6.8K 5% 1/4W F
R623 1-249-431-11 CARBON 15K 5% 1/4W
R624 1-249-436-11 CARBON 39K 5% 1/4W
R625 1-249-418-11 CARBON 1.2K 5% 1/4W F
R626 1-249-420-11 CARBON 1.8K 5% 1/4W F
R627 1-249-418-11 CARBON 1.2K 5% 1/4W F
R628 1-249-420-11 CARBON 1.8K 5% 1/4W F
R629 1-247-841-11 CARBON 2.7K 5% 1/4W
R635 1-247-871-11 CARBON 47K 5% 1/4W
R636 1-249-407-11 CARBON 150 5% 1/4W F
R637 1-249-417-11 CARBON 1K 5% 1/4W F
R638 1-249-417-11 CARBON 1K 5% 1/4W F
R639 1-249-417-11 CARBON 1K 5% 1/4W F
R640 1-247-839-11 CARBON 2.2K 5% 1/4W
R641 1-247-839-11 CARBON 2.2K 5% 1/4W
R642 1-247-839-11 CARBON 2.2K 5% 1/4W
R643 1-247-855-11 CARBON 10K 5% 1/4W
R644 1-247-855-11 CARBON 10K 5% 1/4W
R645 1-247-855-11 CARBON 10K 5% 1/4W
R646 1-247-855-11 CARBON 10K 5% 1/4W
R647 1-247-855-11 CARBON 10K 5% 1/4W
R648 1-247-855-11 CARBON 10K 5% 1/4W
R649 1-249-407-11 CARBON 150 5% 1/4W F
R650 1-249-409-11 CARBON 220 5% 1/4W F
R651 1-247-855-11 CARBON 10K 5% 1/4W
R652 1-247-855-11 CARBON 10K 5% 1/4W
< SWITCH >
S601 1-572-674-11 SWITCH, PUSH (TAPE)
S602 1-572-674-11 SWITCH, PUSH (TUNER/BAND)
S603 1-572-674-11 SWITCH, PUSH (CD PLAY/PAUSE)
S604 1-572-674-11 SWITCH, PUSH (EDIT)
S605 1-572-674-11 SWITCH, PUSH (TUNER MEMORY REPEAT)
S606 1-572-674-11 SWITCH, PUSH (STEREO/MONO PLAY MODE)
S607 1-572-674-11 SWITCH, PUSH (CD STOP)
S608 1-572-674-11 SWITCH, PUSH (CD FF/TUNER UP)
S609 1-572-674-11 SWITCH, PUSH (TUNER PRESET+)
S610 1-572-674-11 SWITCH, PUSH (AMS + TU PRESET+)
S611 1-572-674-11 SWITCH, PUSH (AMS – TU PRESET–)
S612 1-572-674-11 SWITCH, PUSH (POWER)
S613 1-572-674-11 SWITCH, PUSH (CLOCK TIMER SET)
S614 1-572-674-11 SWITCH, PUSH (TIMER ON/OFF)
S615 1-572-674-11 SWITCH, PUSH (ENTER/NEXT)
S616 1-572-674-11 SWITCH, PUSH (FILE SELECT)
S617 1-572-674-11 SWITCH, PUSH (DBFB)
S618 1-572-674-11 SWITCH, PUSH (DISPLAY)
< VIBRATOR >
X601 1-760-096-11 VIBRATOR, CRYSTAL 4.1943MHz
************************************************************
* 1-666-444-11 R/P SWITCH BOARD
****************
< CAPACITOR >
C236 1-126-024-11 ELECT 220uF 20% 16V
C244 1-161-494-00 CERAMIC 0.022uF 25V
PANEL R/P SWITCH
