Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 70 —
< DIODE >
D206 8-719-904-02 DIODE 10E2
D207 8-719-904-02 DIODE 10E2
************************************************************
* 1-670-388-11 SENSOR BOARD
*************
< IC >
RM601 8-749-013-84 IC SPS-447-1
************************************************************
* 1-670-797-11 SW (A) BOARD
************
< SWITCH >
S04 1-771-169-11 SWITCH (TURN TABLE OPERATION DET)
************************************************************
* 1-670-798-11 SW (B) BOARD
************
< SWITCH >
S03 1-771-169-11 SWITCH (TURN TABLE POSITION DET)
************************************************************
* 1-670-799-11 SW (C) BOARD
************
< SWITCH >
S02 1-571-300-31 SWITCH, ROTARY (OPEN/CLOSE DET)
************************************************************
* 1-670-800-11 SW (D) BOARD
************
< SWITCH >
S01 1-571-300-31 SWITCH, ROTARY (OPTICAL PICK-UP DET)
************************************************************
* 1-670-389-11 VR BOARD
*********
< CAPACITOR >
C626 1-162-306-11 CERAMIC 0.01uF 20% 16V
C627 1-162-306-11 CERAMIC 0.01uF 20% 16V
< VARIABLE RESISTOR >
VR601 1-475-807-11 ENCODER, ROTARY (VOLUME)
************************************************************
MISCELLANEOUS
***************
! 6 1-556-035-11 CORD, POWER (UK)
! 6 1-765-558-11 CORD, POWER (EXCEPT UK)
63 1-773-077-11 WIRE (FLAT TYPE) (18 CORE)
163 1-759-417-11 DECK, MECH
251 1-769-856-11 WIRE (FLAT TYPE) (5 CORE)
! 308 8-848-379-31 OPTICAL PICK-UP KSS-213B/S-N
310 1-783-740-11 WIRE (FLAT TYPE) (16 CORE)
M101 X-2625-877-1 MOTOR ASSY (SPINDLE)
M102 X-2625-769-1 MOTOR ASSY (SLED)
HE901 9-980-280-01 E HEAD (ERASE)
HP901 9-980-287-01 HEAD (PLAY)
HRP901 9-980-279-01 HEAD (REC/PLAY)
M103 X-4948-765-1 MOTOR ASSY (TURN TABLE)
M104 X-4948-766-1 MOTOR ASSY (A) (TRAY)
M901 9-980-281-01 MOTOR (CAPSTAN/REEL)
! PT302 1-431-960-11 TRANSFORMER, POWER
SW202 9-980-270-01 LEAF SWITCH (A DECK)
SW203 9-980-270-01 LEAF SWITCH (B DECK)
SW204 9-980-271-01 LEAF SWITCH (PLAY)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-475-826-11 REMOTE COMMANDER (RM-SG5)
1-501-594-11 ANTENNA, (FM)
1-501-374-11 ANTENNA , LOOP
3-862-423-11 MANUAL, INSTRUCTION (ENGLISH)
3-862-423-41 MANUAL, INSTRUCTION
(FRENCH/SPANISH/PORTUGUESE) (AEP)
3-862-423-51 MANUAL, INSTRUCTION (GERMAN) (AEP, G)
3-862-423-61 MANUAL, INSTRUCTION (DUTCH/ITALIAN) (AEP)
3-862-423-71 MANUAL, INSTRUCTION
(SWEDISH/DANISH/FINNISH) (AED)
3-862-423-81 MANUAL, INSTRUCTION (POLISH/RUSSIAN) (AEP)
3-862-424-11 MANUAL, INSTRUCTION (HANGARIAN) (AEP)
3-862-424-21 MANUAL, INSTRUCTION (GREEK) (AEP)
3-862-424-31 MANUAL, INSTRUCTION (CZECH) (AEP)
3-862-424-41 MANUAL, INSTRUCTION (TURKISH) (AEP)
4-982-031-01 COVER, BATTERY (for RM-SG5)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-647-79 SCREW +BVTP 3 × 10 TYPE2 IT-3
#2 7-682-547-04 SCREW +BVTT 3 × 6 (S)
#3 7-682-548-04 SCREW +B 3 × 8
#4 7-685-106-19 SCREW +P 2 × 10 TYPE2 SLIT
#5 7-685-131-19 SCREW +P 2.6 × 4 TYPE2 SLIT
#6 7-685-139-29 SCREW, TAPPING, (M2.6 × 20)
#7 7-685-134-19 SCREW +PTPWH 2.6 × 8 (TYPE2)
#8 7-685-138-19 SCREW +BTP 2.6 × 16 TYPE2 N-S
#9 7-624-118-01 RING, RETAINING E-2.5
#10 7-685-903-31 SCREW +PTPWH 3 × 10 (TYPE2)
#11 7-685-246-19 SCREW +KTP 3 × 8 TYPE2 NON-SLIT
#12 7-685-547-14 SCREW +BTP 3 × 10 TYPE2 N-S
#13 7-685-547-19 SCREW +BTP 3 × 10 TYPE2 N-S
#14 7-685-549-14 SCREW +BTP 3 × 14 TYPE2 N-S
#15 7-685-645-79 SCREW +BTP 3 × 6 TYPE2 N-S
#16 7-685-660-79 SCREW +PTPWH 4 × 10 TYPE 2
#17 7-685-903-21 SCREW +PTPWH 3 × 8 (TYPE2)
#18 7-621-255-15 SCREW +P 2 × 3
SW (A) SW (B) SW (C) SW (D) VR
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
HCD-RX33
Sony Corporation
Home A&V Products Company
9-922-865-11
98E167549-1
Printed in Hungary ©1998.5
Published by Quality Assurance Dept.
(Shibaura)
SENSORR/P SWITCH
