– 39 – – 40 –
HCD-V818
8-4. PRINTED WIRING BOARD – CD SECTION –
• See page 22 for Circuit Boards Location.
Ref. No. Location
• Semiconductor
Location
IC101 B-1
IC103 A-2
Q102 A-2
Q103 A-2
Ref. No. Location
• Semiconductor
Location
IC102 B-2
IC104 B-3
Q101 A3
KSS-213D/Q-NP
(Page 46)
