– 117 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
PANEL
D624 8-719-058-03 DIODE SEL5423E-TP15 (9 TAPE A)
D625 8-719-058-03 DIODE SEL5423E-TP15 (( TAPE A)
D626 8-719-057-97 DIODE SEL5923A-TP15 (PBC)
D627 8-719-057-97 DIODE SEL5923A-TP15 (PBC OFF)
D628 8-719-057-97 DIODE SEL5923A-TP15 (VIDEO CD)
D630 8-719-057-97 DIODE SEL5923A-TP15 (SONIC FORMATION)
D651 8-719-063-93 DIODE SLR325VC-N-T32 (r REC)
D652 8-719-057-97 DIODE SEL5923A-TP15 (P PAUSE)
D804 8-719-988-62 DIODE 1SS355
D805 8-719-988-62 DIODE 1SS355
D806 8-719-988-62 DIODE 1SS355
D807 8-719-988-62 DIODE 1SS355
< FILTER >
FL601 1-233-289-21 FILTER, CHIP EMI
FL602 1-233-289-21 FILTER, CHIP EMI
FL801 1-233-289-21 FILTER, CHIP EMI
FL802 1-233-289-21 FILTER, CHIP EMI
FL851 1-233-289-21 FILTER, CHIP EMI
< IC >
IC601 8-759-546-36 IC TMP87CM74AF-6731
IC602 8-749-011-22 IC GP1U27X
IC603 8-759-495-25 IC BA3833FP-E2
IC801 8-759-496-11 IC TMP87CH48DF-4825
IC851 8-759-498-98 IC MSM6653A-517GS-K
< JUMPER RESISTOR >
JR903 1-216-296-91 SHORT 0
JR904 1-216-296-91 SHORT 0
JR905 1-216-296-91 SHORT 0
JR906 1-216-295-91 SHORT 0
JR907 1-216-296-91 SHORT 0
JR908 1-216-296-91 SHORT 0
JR909 1-216-296-91 SHORT 0
JR910 1-216-296-91 SHORT 0
JR911 1-216-296-91 SHORT 0
JR912 1-216-295-91 SHORT 0
JR913 1-216-296-91 SHORT 0
JR914 1-216-296-91 SHORT 0
JR915 1-216-296-91 SHORT 0
JR916 1-216-296-91 SHORT 0
JR917 1-216-296-91 SHORT 0
JR918 1-216-296-91 SHORT 0
JR919 1-216-295-91 SHORT 0
JR920 1-216-295-91 SHORT 0
JR921 1-216-295-91 SHORT 0
JR922 1-216-295-91 SHORT 0
JR923 1-216-296-91 SHORT 0
JR924 1-216-296-91 SHORT 0
JR925 1-216-295-91 SHORT 0
JR926 1-216-295-91 SHORT 0
JR927 1-216-295-91 SHORT 0
JR928 1-216-295-91 SHORT 0
< COIL >
L601 1-412-031-11 INDUCTOR CHIP 47uH
L602 1-412-031-11 INDUCTOR CHIP 47uH
L851 1-412-031-11 INDUCTOR CHIP 47uH
< FLUORECENT INDICATOR >
ND601 1-517-731-21 INDICATOR TUBE, FLUORESCENT
< TRANSISTOR >
Q601 8-729-118-00 TRANSISTOR 2SB1116-L
Q602 8-729-118-00 TRANSISTOR 2SB1116-L
Q603 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q607 8-729-027-60 TRANSISTOR DTC144TKA-T146
Q608 8-729-027-60 TRANSISTOR DTC144TKA-T146
Q609 8-729-027-60 TRANSISTOR DTC144TKA-T146
Q610 8-729-027-60 TRANSISTOR DTC144TKA-T146
Q611 8-729-027-60 TRANSISTOR DTC144TKA-T146
Q618 8-729-027-60 TRANSISTOR DTC144TKA-T146
Q701 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q702 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q851 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q958 1-801-900-53 TRANSISTOR DTC114EKA
Q959 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q960 8-729-027-23 TRANSISTOR DTA114EKA-T146
< RESISTOR >
R601 1-216-121-91 RES,CHIP 1M 5% 1/10W
R602 1-216-025-91 RES,CHIP 100 5% 1/10W
R604 1-216-073-00 METAL CHIP 10K 5% 1/10W
R605 1-216-073-00 METAL CHIP 10K 5% 1/10W
R606 1-216-073-00 METAL CHIP 10K 5% 1/10W
R607 1-216-073-00 METAL CHIP 10K 5% 1/10W
R608 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R609 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R610 1-216-025-91 RES,CHIP 100 5% 1/10W
R611 1-216-025-91 RES,CHIP 100 5% 1/10W
R612 1-216-017-91 RES,CHIP 47 5% 1/10W
R613 1-216-081-00 METAL CHIP 22K 5% 1/10W
R614 1-216-081-00 METAL CHIP 22K 5% 1/10W
R616 1-216-097-91 RES,CHIP 100K 5% 1/10W
R618 1-216-089-91 RES,CHIP 47K 5% 1/10W
R619 1-216-089-91 RES,CHIP 47K 5% 1/10W
R621 1-216-075-00 METAL CHIP 12K 5% 1/10W
R622 1-216-039-00 METAL CHIP 390 5% 1/10W
R623 1-216-041-00 METAL CHIP 470 5% 1/10W
R624 1-216-045-00 METAL CHIP 680 5% 1/10W
R625 1-216-047-91 METAL CHIP 820 5% 1/10W
R626 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R627 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R628 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R629 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R630 1-216-063-91 METAL CHIP 3.9K 5% 1/10W
R631 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R632 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R633 1-216-075-00 METAL CHIP 12K 5% 1/10W
R636 1-216-075-00 METAL CHIP 12K 5% 1/10W
R649 1-216-075-00 METAL CHIP 12K 5% 1/10W
R650 1-216-039-00 METAL CHIP 390 5% 1/10W
R651 1-216-041-00 METAL CHIP 470 5% 1/10W
R652 1-216-045-00 METAL CHIP 680 5% 1/10W
R653 1-216-047-91 METAL CHIP 820 5% 1/10W
