HCD-VM330AV
• VIDEO BOARD IC502 M30622MGA-A58FP (VIDEO CD CONTROLLER)
Pin No. Pin Name I/O Description
1 SENSE I
Internal status (SENSE) signal input from the CXD3068Q (IC101)
2 SENSE CLK O
Sense serial data reading clock signal output to the CXD3068Q (IC101)
3 RESOLUTION O
Serial data output to the Y amplifier (IC303)
4 CROMA LEVEL O
Serial data latch pulse output to the C amplifier (IC302)
5 DSP CLK O
Serial data transfer clock signal output to the CXD3068Q (IC101)
6 TSENS I
Disc tray status detection signal input terminal Not used (open)
7 REMOTE IN I
Remote control signal input terminal Not used (open)
8BYTEI
External data bus line byte selection signal input terminal
“L”: 16 bit, “H”: 8 bit (fixed at “L”)
9 CNVSS —
Ground terminal Not used
10 DSP MUTING O
Muting on/off control signal output to the CXD3068Q (IC101) “H”: muting on
11 CTRL1 O
Clock selection signal output to the CXD3068Q (IC101)
“L”: 16.9344 MHz (double speed), “H”: 33.8688 MHz
12 XRESET I
Reset signal input from the system controller (IC801) “L”: reset
13 XOUT O
Main system clock output terminal (10 MHz)
14 VSS —
Ground terminal
15 XIN I
Main system clock input terminal (10 MHz)
16 VCC —
Power supply terminal (+5V)
17 NMI I
Non-maskable interrupt input terminal (fixed at “H” in this set)
18 SCOR I
Subcode sync (S0+S1) detection signal input from the CXD3068Q (IC101)
19 DSENS I
Disc status detection signal input terminal Not used (open)
20 CL680 HINT I
Interrupt request signal input from the CL680T (IC505)
21 H.SYNC IN I
Horizontal synchronized signal input from the CL680T (IC505)
22 BGP O
BGP signal output to the C amplifier (IC302)
23 ——
Not used (open)
24 PWM3 O
RFDC PWM signal output to the CXA2581N (IC103)
25 ——
Not used (open)
26 PWM2 O
PWM signal output to the CXA2581N (IC103)
27 ——
Not used (open)
28 PWM1 O
Focus servo drive PWM signal output to the CXA2581N (IC103)
29 I2C.CLK I/O
Communication data reading clock signal input or transfer clock signal output with the display
controller (IC701) and system controller (IC801)
30 I2C.DATA I/O
Communication data bus with the display controller (IC701) and system controller (IC801)
31 DATA1O O
Serial data output terminal Not used
32 DATA1I I
Serial data input terminal Not used
33 CLK1 O
Serial data transfer clock signal output terminal Not used
34 RTS1 I
Reset signal input terminal Not used
35 DATAO O
Serial data output to the CL680T (IC505) and D/A converter (IC509)
36 DATAI I
Serial data input from the CL680T (IC505)
37
CLK1
O
Serial data transfer clock signal output to the CL680T (IC505) and D/A converter (IC509)
38 P.ON O
Power on/off control signal output terminal Not used (open)
39 BUS XRDY I
Ready signal input terminal Not used (fixed at “H”)
40 BUS O
Not used (open)
41 BUS XHOLD I
Hold signal input terminal Not used (fixed at “H”)
42, 43 BUS O
Not used (open)
44
OSD.LANGUAGE
I
Destination setting terminal “L”: chinese, “H”: others (fixed at “H” in this set)
45 VSYNC I
Vertical synchronized signal input from theCL680T (IC505) “L” active
