– 129 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C802 1-162-292-31 CERAMIC 680PF 10% 50V
C803 1-162-286-31 CERAMIC 220PF 10% 50V
C804 1-126-967-11 ELECT 47uF 20% 50V
C807 1-128-560-11 ELECT 22uF 20% 100V
C808 1-130-777-00 FILM 0.1uF 10% 100V
C809 1-130-777-00 FILM 0.1uF 10% 100V
C810 1-128-562-11 ELECT 47uF 20% 100V
C811 1-130-493-00 MYLAR 0.068uF 5% 50V
C812 1-130-493-00 MYLAR 0.068uF 5% 50V
C813 1-161-494-00 CERAMIC 0.022uF 25V
C814 1-162-294-31 CERAMIC 0.001uF 10% 50V
C815 1-128-562-11 ELECT 47uF 20% 100V
C830 1-107-714-11 ELECT 10uF 20% 50V
C831 1-126-964-11 ELECT 10uF 20% 50V
C832 1-126-967-11 ELECT 47uF 20% 50V
C841 1-127-811-11 ELECT 3300uF 20% 50V
C842 1-127-814-11 ELECT 3300uF 20% 80V
(VR50)
C842 1-127-815-11 ELECT 3300uF 20% 100V
(VR70)
C844 1-130-777-00 FILM 0.1uF 10% 100V
C845 1-126-943-11 ELECT 2200uF 20% 25V
C847 1-164-159-21 CERAMIC 0.1uF 50V
C848 1-164-159-21 CERAMIC 0.1uF 50V
C849 1-164-159-21 CERAMIC 0.1uF 50V
C850 1-107-721-11 ELECT 4.7uF 20% 100V
C851 1-128-582-11 ELECT 10uF 20% 100V
C852 1-162-292-31 CERAMIC 680PF 10% 50V
C853 1-162-286-31 CERAMIC 220PF 10% 50V
C854 1-126-967-11 ELECT 47uF 20% 50V
C857 1-128-560-11 ELECT 22uF 20% 100V
C858 1-164-159-21 CERAMIC 0.1uF 50V
C859 1-164-159-21 CERAMIC 0.1uF 50V
C861 1-130-493-00 MYLAR 0.068uF 5% 50V
C862 1-130-493-00 MYLAR 0.068uF 5% 50V
C891 1-127-811-11 ELECT 3300uF 20% 50V
C892 1-127-814-11 ELECT 3300uF 20% 80V
(VR50)
C892 1-127-815-11 ELECT 3300uF 20% 100V
(VR70)
C894 1-130-777-00 FILM 0.1uF 10% 100V
C895 1-107-721-11 ELECT 4.7uF 20% 100V
C904 1-126-964-11 ELECT 10uF 20% 50V
C905 1-126-948-11 ELECT 100uF 20% 35V
< CONNECTOR >
CN803 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
CN804 1-766-921-11 CONNECTOR, BOARD TO BOARD 10P
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-991-33 DIODE 1SS133T-77
D405 8-719-991-33 DIODE 1SS133T-77
D406 8-719-991-33 DIODE 1SS133T-77
D801 8-719-991-33 DIODE 1SS133T-77
D802 8-719-119-04 DIODE RD18F-T7B2
D803 8-719-991-33 DIODE 1SS133T-77
D804 8-719-991-33 DIODE 1SS133T-77
D805 8-719-991-33 DIODE 1SS133T-77
D831 8-719-510-68 DIODE D5SBA20F01
D833 8-719-200-82 DIODE 11ES2
D834 8-719-200-82 DIODE 11ES2
D835 8-719-200-82 DIODE 11ES2
D836 8-719-200-82 DIODE 11ES2
D841 8-719-975-85 DIODE ERB83-004
D842 8-719-975-85 DIODE ERB83-004
D843 8-719-975-85 DIODE ERB83-004
D844 8-719-975-85 DIODE ERB83-004
D851 8-719-991-33 DIODE 1SS133T-77
D852 8-719-119-04 DIODE RD18F-T7B2
D911 8-719-934-25 DIODE HZS33-1L
D912 8-719-109-89 DIODE RD5.6ESB2
< IC >
IC801 8-749-015-37 IC STK411-240E
< TRANSISTOR >
Q401 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q402 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q431 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q432 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q433 8-729-620-05 TRANSISTOR 2SC2603-EF
Q434 8-729-620-05 TRANSISTOR 2SC2603-EF
Q437 8-729-620-05 TRANSISTOR 2SC2603-EF
Q439 8-729-620-05 TRANSISTOR 2SC2603-EF
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q803 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q804 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q805 8-729-231-55 TRANSISTOR 2SC2878-AB
Q831 8-729-029-86 TRANSISTOR DTC124ESA
Q832 8-729-620-05 TRANSISTOR 2SC2603-EF
Q833 8-729-029-40 TRANSISTOR DTA124ESA
Q834 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q855 8-729-231-55 TRANSISTOR 2SC2878-AB
Q903 8-729-048-52 TRANSISTOR 2SA1932
Q904 8-729-661-93 TRANSISTOR 2SA1115
< RESISTOR >
!R401 1-215-868-00 METAL OXIDE 680 5% 1W F
(VR70)
!R401 1-216-431-11 METAL OXIDE 560 5% 1W F
(VR50)
R406 1-249-437-11 CARBON 47K 5% 1/4W
R407 1-249-437-11 CARBON 47K 5% 1/4W
R429 1-249-437-11 CARBON 47K 5% 1/4W
R431 1-249-438-11 CARBON 56K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R434 1-247-863-91 CARBON 22K 5% 1/4W
R435 1-249-425-11 CARBON 4.7K 5% 1/4W F
R437 1-249-429-11 CARBON 10K 5% 1/4W
R439 1-249-425-11 CARBON 4.7K 5% 1/4W F
R440 1-247-863-91 CARBON 22K 5% 1/4W
R441 1-249-435-11 CARBON 33K 5% 1/4W
PA
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
