– 133 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
TRANS
TABLE SENSOR
S636 1-554-303-21 SWITCH, TACTILE (EFFECT)
S637 1-554-303-21 SWITCH, TACTILE (P.FILE MEMORY)
S660 1-554-303-21 SWITCH, TACTILE (˜)
S701 1-473-392-11 ENCODER, ROTARY (VOLUME)
**************************************************************
* 1-659-058-13 TABLE SENSOR BOARD
******************
< IC >
IC202 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R207 1-249-416-11 CARBON 820 5% 1/4W F
**************************************************************
* 1-672-193-11 TC-A BOARD
**********
< DIODE >
D631 8-719-058-03 DIODE SEL5423E-TP15 (·)(DECK A)
D632 8-719-058-03 DIODE SEL5423E-TP15 (ª)(DECK A)
< RESISTOR >
R701 1-249-417-11 CARBON 1K 5% 1/4W F
R702 1-249-418-11 CARBON 1.2K 5% 1/4W F
R703 1-249-420-11 CARBON 1.8K 5% 1/4W F
R704 1-249-422-11 CARBON 2.7K 5% 1/4W F
R705 1-247-843-11 CARBON 3.3K 5% 1/4W
R706 1-249-425-11 CARBON 4.7K 5% 1/4W F
R707 1-247-804-11 CARBON 75 5% 1/4W
R708 1-247-804-11 CARBON 75 5% 1/4W
< SWITCH >
S641 1-554-303-21 SWITCH, TACTILE (·)(DECK A)
S642 1-554-303-21 SWITCH, TACTILE (ª)(DECK A)
S643 1-554-303-21 SWITCH, TACTILE (π)(DECK A)
S644 1-554-303-21 SWITCH, TACTILE (º)(DECK A)
S645 1-554-303-21 SWITCH, TACTILE (‚)(DECK A)
S646 1-554-303-21 SWITCH, TACTILE (DOLBY NR)
S647 1-554-303-21 SWITCH, TACTILE (DIRECTION)
**************************************************************
* 1-672-194-11 TC-B BOARD
**********
< DIODE >
D635 8-719-058-03 DIODE SEL5423E-TP15 (ª)(DECK B)
D636 8-719-058-03 DIODE SEL5423E-TP15 (·)(DECK B)
D637 8-719-057-97 DIODE SEL5923A-TP15 (P)(DECK B)
D638 8-719-058-04 DIODE SEL5223S-TP15 (r REC)(DECK B)
< RESISTOR >
R711 1-249-410-11 CARBON 270 5% 1/4W F
R712 1-249-411-11 CARBON 330 5% 1/4W
R713 1-249-413-11 CARBON 470 5% 1/4W F
R714 1-249-414-11 CARBON 560 5% 1/4W F
R715 1-249-415-11 CARBON 680 5% 1/4W F
R716 1-249-417-11 CARBON 1K 5% 1/4W F
R717 1-249-418-11 CARBON 1.2K 5% 1/4W F
R718 1-249-420-11 CARBON 1.8K 5% 1/4W F
R719 1-249-422-11 CARBON 2.7K 5% 1/4W F
R720 1-247-804-11 CARBON 75 5% 1/4W
R721 1-247-804-11 CARBON 75 5% 1/4W
R722 1-247-807-31 CARBON 100 5% 1/4W
R723 1-249-407-11 CARBON 150 5% 1/4W F
< SWITCH >
S651 1-554-303-21 SWITCH, TACTILE (·)(DECK B)
S652 1-554-303-21 SWITCH, TACTILE (ª)(DECK B)
S653 1-554-303-21 SWITCH, TACTILE (π)(DECK B)
S654 1-554-303-21 SWITCH, TACTILE (º)(DECK B)
S655 1-554-303-21 SWITCH, TACTILE (‚)(DECK B)
S656 1-554-303-21 SWITCH, TACTILE (P)(DECK B)
S657 1-554-303-21 SWITCH, TACTILE (r REC)(DECK B)
S658 1-554-303-21 SWITCH, TACTILE (HI-SPEED DUB)
S659 1-554-303-21 SWITCH, TACTILE (CD SYNCHRO)
**************************************************************
1-673-110-11 TRANS BOARD
***********
< CAPACITOR >
C843 1-130-777-00 FILM 0.1uF 10% 100V
C893 1-130-777-00 FILM 0.1uF 10% 100V
C961 1-162-306-11 CERAMIC 0.01uF 20% 16V
C963 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
* CN901 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
* CN952 1-564-528-11 PLUG, CONNECTOR 13P
< DIODE >
D832 8-719-510-68 DIODE D5SBA20F01
< FUSE >
!F951 1-532-505-31 FUSE (T5AL/250V)(VR70)
!F951 1-532-506-31 FUSE (T6.3AL/250V)(VR50)
!F961 1-532-506-31 FUSE (T6.3AL/250V)(VR70)
!F961 1-533-949-31 FUSE (T8AL/250V)(VR50)
!F962 1-532-506-31 FUSE (T6.3AL/250V)(VR70)
!F962 1-533-949-31 FUSE (T8AL/250V)(VR50)
!F963 1-532-506-31 FUSE (T6.3AL/250V)
!F964 1-532-506-31 FUSE (T6.3AL/250V)
< FUSE HOLDER >
FH951 1-533-233-21 HOLDER, FUSE
FH952 1-533-233-21 HOLDER, FUSE
FH961 1-533-233-21 HOLDER, FUSE
FH962 1-533-233-21 HOLDER, FUSE
FH963 1-533-233-21 HOLDER, FUSE
TC-A TC-B
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
