– 136 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
VIDEO
R457 1-216-025-91 RES,CHIP 100 5% 1/10W
R458 1-216-025-91 RES,CHIP 100 5% 1/10W
R459 1-216-025-91 RES,CHIP 100 5% 1/10W
R461 1-216-025-91 RES,CHIP 100 5% 1/10W
R462 1-216-025-91 RES,CHIP 100 5% 1/10W
R463 1-216-025-91 RES,CHIP 100 5% 1/10W
R464 1-216-025-91 RES,CHIP 100 5% 1/10W
R501 1-216-025-91 RES,CHIP 100 5% 1/10W
R502 1-216-025-91 RES,CHIP 100 5% 1/10W
R503 1-216-025-91 RES,CHIP 100 5% 1/10W
R504 1-216-025-91 RES,CHIP 100 5% 1/10W
R505 1-216-025-91 RES,CHIP 100 5% 1/10W
R506 1-216-025-91 RES,CHIP 100 5% 1/10W
R507 1-216-073-00 METAL CHIP 10K 5% 1/10W
R508 1-216-081-00 METAL CHIP 22K 5% 1/10W
R509 1-216-081-00 METAL CHIP 22K 5% 1/10W
R510 1-216-081-00 METAL CHIP 22K 5% 1/10W
R511 1-216-081-00 METAL CHIP 22K 5% 1/10W
R512 1-216-081-00 METAL CHIP 22K 5% 1/10W
R513 1-216-081-00 METAL CHIP 22K 5% 1/10W
R514 1-216-081-00 METAL CHIP 22K 5% 1/10W
R516 1-216-073-00 METAL CHIP 10K 5% 1/10W
R517 1-216-073-00 METAL CHIP 10K 5% 1/10W
R518 1-216-073-00 METAL CHIP 10K 5% 1/10W
R519 1-216-025-91 RES,CHIP 100 5% 1/10W
R520 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R523 1-216-013-00 METAL CHIP 33 5% 1/10W
R530 1-216-081-00 METAL CHIP 22K 5% 1/10W
R531 1-216-025-91 RES,CHIP 100 5% 1/10W
R532 1-216-025-91 RES,CHIP 100 5% 1/10W
R533 1-216-025-91 RES,CHIP 100 5% 1/10W
R534 1-216-073-00 METAL CHIP 10K 5% 1/10W
R535 1-216-073-00 METAL CHIP 10K 5% 1/10W
R536 1-216-033-00 METAL CHIP 220 5% 1/10W
R537 1-216-025-91 RES,CHIP 100 5% 1/10W
R538 1-216-073-00 METAL CHIP 10K 5% 1/10W
R542 1-216-049-91 RES,CHIP 1K 5% 1/10W
R543 1-216-685-11 METAL CHIP 27K 0.5% 1/10W
R544 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W
R545 1-216-025-91 RES,CHIP 100 5% 1/10W
R546 1-216-049-91 RES,CHIP 1K 5% 1/10W
R547 1-216-295-91 SHORT 0
R548 1-216-049-91 RES,CHIP 1K 5% 1/10W
R549 1-216-025-91 RES,CHIP 100 5% 1/10W
R550 1-216-025-91 RES,CHIP 100 5% 1/10W
R551 1-216-025-91 RES,CHIP 100 5% 1/10W
R552 1-216-025-91 RES,CHIP 100 5% 1/10W
R554 1-216-025-91 RES,CHIP 100 5% 1/10W
R555 1-216-121-91 RES,CHIP 1M 5% 1/10W
R556 1-216-025-91 RES,CHIP 100 5% 1/10W
R557 1-216-025-91 RES,CHIP 100 5% 1/10W
R558 1-216-073-00 METAL CHIP 10K 5% 1/10W
R559 1-216-073-00 METAL CHIP 10K 5% 1/10W
R560 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R561 1-216-049-91 RES,CHIP 1K 5% 1/10W
R562 1-216-025-91 RES,CHIP 100 5% 1/10W
R563 1-216-025-91 RES,CHIP 100 5% 1/10W
R564 1-216-025-91 RES,CHIP 100 5% 1/10W
R565 1-216-025-91 RES,CHIP 100 5% 1/10W
R566 1-216-025-91 RES,CHIP 100 5% 1/10W
R567 1-216-073-00 METAL CHIP 10K 5% 1/10W
R568 1-216-073-00 METAL CHIP 10K 5% 1/10W
R569 1-216-073-00 METAL CHIP 10K 5% 1/10W
R572 1-216-073-00 METAL CHIP 10K 5% 1/10W
R573 1-216-073-00 METAL CHIP 10K 5% 1/10W
R574 1-216-073-00 METAL CHIP 10K 5% 1/10W
R577 1-216-081-00 METAL CHIP 22K 5% 1/10W
R578 1-216-081-00 METAL CHIP 22K 5% 1/10W
R579 1-216-073-00 METAL CHIP 10K 5% 1/10W
R580 1-216-073-00 METAL CHIP 10K 5% 1/10W
< SWITCH >
S501 1-571-395-11 SWITCH, SLIDE
(SYSTEM SELECT NTSC = AUTO + PAL)
< VIBRATOR >
X501 1-767-510-11 VIBRATOR, CERAMIC (10MHz)
X503 1-767-519-11 VIBRATOR, CRYSTAL (27MHz)
**************************************************************
MISCELLANEOUS
*************
1 1-769-977-11 WIRE (FLAT TYPE) (13 CORE)
5 1-693-420-12 TUNER UNIT (FM/AM)
61 1-773-002-11 WIRE (FLAT TYPE) (15 CORE)(80mm)
62 1-773-034-11 WIRE (FLAT TYPE) (15 CORE)(420mm)
152 1-569-007-11 ADAPTOR, CONVERSION 2P (IA)
152 1-569-008-21 ADAPTOR, CONVERSION 2P (EXCEPT IA)
156 1-790-660-11 WIRE (FLAT TYPE) (23 CORE)
158 1-790-288-11 WIRE (FLAT TYPE) (13 CORE)
160 1-773-006-11 WIRE (FLAT TYPE) (15 CORE)
161 1-773-056-11 WIRE (FLAT TYPE) (17 CORE)
507 1-452-925-21 MAGNET ASSY
!601 8-820-020-02 OPTICAL PICK-UP KSS-213D/Q-NP
602 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
!CNP901 1-558-943-41 CORD, POWER (IA)
!CNP901 1-575-651-21 CORD, POWER (EXCEPT IA)
FL601 1-517-839-11 INDICATOR TUBE, FLUORESCENT (VR70)
FL601 1-517-840-11 INDICATOR TUBE, FLUORESCENT (VR50)
HP101 A-2056-681-B DECK (A) ASSY, HEAD (230AWR2)
HP101 A-2056-683-B DECK (A) ASSY, HEAD (230PWR2)
HRPE101 A-2056-682-B DECK (B) ASSY, HEAD (230AWR2)
HRPE101 A-2056-684-B DECK (B) ASSY, HEAD (230PWR2)
M1 A-2004-628-A MOTOR ASSY, CAPSTAN
M101 X-4917-523-4 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M201 A-4660-977-A MOTOR ASSY (TABLE)
M901 1-698-792-11 FAN, DC (VR50)
M901 1-763-072-11 FAN, DC (VR70)
!T951 1-433-604-11 TRANSFORMER, POWER (VR50)
!T951 1-433-606-11 TRANSFORMER, POWER (VR70)
**************************************************************
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
