66
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-VX222
The components identified by mark 0 or
dotted line with mark 0 are critical for
safety.
Replace only with part number specified.
A-4476-990-A POWER AMP BOARD, COMPLETE (E,EA,IA,SP)
A-4725-699-A POWER AMP BOARD, COMPLETE (TW)
A-4726-000-A POWER AMP BOARD, COMPLETE (TH)
A-4726-270-A POWER AMP BOARD, COMPLETE (E91)
********************************
< CAPACITOR >
C501 1-126-964-11 ELECT 10uF 20% 50V
C502 1-162-294-31 CERAMIC 0.001uF 10% 50V
C503 1-162-282-31 CERAMIC 100PF 10% 50V
C504 1-128-551-11 ELECT 22uF 20% 25V
C507 1-130-493-00 MYLAR 0.068uF 5% 50V
C508 1-130-493-00 MYLAR 0.068uF 5% 50V
C509 1-126-965-11 ELECT 22uF 20% 50V
C511 1-162-306-11 CERAMIC 0.01uF 30% 16V
C512 1-162-294-31 CERAMIC 0.001uF 10% 50V
(TW)
C513 1-162-294-31 CERAMIC 0.001uF 10% 50V
(TW)
C541 1-137-749-11 MYLAR 0.1uF 100V
C542 1-135-832-11 ELECT 2200uF 20% 50V
C542 1-135-832-21 ELECT 2200uF 20% 50V
C543 1-164-159-21 CERAMIC 0.1uF 50V
C544 1-126-942-61 ELECT 1000uF 20% 25V
C545 1-128-549-11 ELECT 3300uF 20% 35V
C551 1-126-964-11 ELECT 10uF 20% 50V
C552 1-162-294-31 CERAMIC 0.001uF 10% 50V
C553 1-162-282-31 CERAMIC 100PF 10% 50V
C554 1-128-551-11 ELECT 22uF 20% 25V
C557 1-130-493-00 MYLAR 0.068uF 5% 50V
C558 1-130-493-00 MYLAR 0.068uF 5% 50V
C559 1-126-965-11 ELECT 22uF 20% 50V
C591 1-137-749-11 MYLAR 0.1uF 100V
C592 1-135-832-11 ELECT 2200uF 20% 50V
C592 1-135-832-21 ELECT 2200uF 20% 50V
< CONNECTOR >
CN502 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
D541 8-719-510-68 DIODE D5SBA204101
D542 8-719-200-82 DIODE 11ES2
D543 8-719-200-82 DIODE 11ES2
D551 8-719-991-33 DIODE 1SS133T-77
< TERMINAL >
EP501 1-537-738-21 TERMINAL, EARTH (TW)
* EP502 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 8-749-016-93 IC STK402-070S
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q503 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q504 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q551 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q581 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W
R502 1-249-438-11 CARBON 56K 5% 1/4W
R503 1-249-418-11 CARBON 1.2K 5% 1/4W
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W
R506 1-249-431-11 CARBON 15K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
0R508 1-217-151-00 METAL 0.22 10% 2W
R509 1-260-076-11 CARBON 10 5% 1/2W
0R510 1-217-151-00 METAL 0.22 10% 2W
0R511 1-212-881-11 FUSIBLE 100 5% 1/4W
0R512 1-202-972-61 FUSIBLE 1 5% 1/4W
R513 1-249-433-11 CARBON 22K 5% 1/4W
R514 1-249-421-11 CARBON 2.2K 5% 1/4W
R515 1-249-433-11 CARBON 22K 5% 1/4W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-421-11 CARBON 2.2K 5% 1/4W
R518 1-249-429-11 CARBON 10K 5% 1/4W
R519 1-249-433-11 CARBON 22K 5% 1/4W
R541 1-260-115-11 CARBON 22K 5% 1/2W
R551 1-249-417-11 CARBON 1K 5% 1/4W
R552 1-249-438-11 CARBON 56K 5% 1/4W
R553 1-249-418-11 CARBON 1.2K 5% 1/4W
R554 1-249-438-11 CARBON 56K 5% 1/4W
R555 1-249-417-11 CARBON 1K 5% 1/4W
R556 1-249-431-11 CARBON 15K 5% 1/4W
R557 1-249-441-11 CARBON 100K 5% 1/4W
0R558 1-217-151-00 METAL 0.22 10% 2W
R559 1-260-076-11 CARBON 10 5% 1/2W
0R560 1-217-151-00 METAL 0.22 10% 2W
0R561 1-212-881-11 FUSIBLE 100 5% 1/4W
R581 1-249-435-11 CARBON 33K 5% 1/4W
R582 1-249-435-11 CARBON 33K 5% 1/4W
R591 1-260-115-11 CARBON 22K 5% 1/2W
0R592 1-219-591-11 FUSIBLE 0.1 5% 1/2W
0R593 1-219-119-11 FUSIBLE 0.1 5% 1/4W
******************************************************
1-681-445-11 SUB TRANS BOARD
***************
< CAPACITOR >
0C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
C902 1-126-768-11 ELECT 2200uF 20% 16V
C903 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN2 1-568-106-11 PIN, CONNECTOR 4P (E,EA,IA,SP,TW)
CN2 1-564-321-00 PIN, CONNECTOR 2P (E91,TH)
CN901 1-564-321-00 PIN, CONNECTOR 2P
CN903 1-785-315-11 PIN, CONNECTOR (STRAIGHT) 3P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
D902 8-719-200-82 DIODE 11ES2
D903 8-719-200-82 DIODE 11ES2
SUB TRANS
POWER AMP
To Next Page
