67
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-VX222
D904 8-719-200-82 DIODE 11ES2
D905 8-719-200-82 DIODE 11ES2
< IC >
IC901 8-759-158-62 IC TA78057S
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R902 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0RY901 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0T901 1-435-828-11 TRANSFORMER, POWER
********************************************************
1-681-444-11 TRANS BOARD
***********
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C911 1-128-553-11 ELECT 220uF 20% 63V
C912 1-126-964-11 ELECT 10uF 20% 50V
C913 1-126-968-11 ELECT 100uF 20% 50V
C915 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN915 1-564-528-11 PLUG, CONNECTOR 13P
< DIODE >
D911 8-719-200-82 DIODE 11ES2
D912 8-719-982-20 DIODE MTZJ-30B
D913 8-719-109-89 DIODE RD5.6ESB2
< FUSE >
0F914 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) T6.3AL 250V
0F919 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) T4AL 250V
(E,EA,IA,SP,TW)
0F920 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) T6.3AL 250V
< TRANSISTOR >
Q911 8-729-048-52 TRANSISTOR 2SA1932(TP)
< RESISTOR >
R905 1-249-429-11 CARBON 10K 5% 1/4W
0R911 1-217-637-00 FUSIBLE 1 5% 1/4W
R912 1-249-417-11 CARBON 1K 5% 1/4W
R913 1-249-429-11 CARBON 10K 5% 1/4W
R915 1-247-807-31 CARBON 100 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
0R919 1-219-122-91 FUSIBLE 0.33 5% 1/4W
0R920 1-219-122-91 FUSIBLE 0.33 5% 1/4W
< SWITCH >
0S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(E,EA,IA,SP,TW)
< TRANSFORMER >
0T911 1-437-221-11 TRANSFORMER, POWER
******************************************************
A-4726-022-A VIDEO BOARD, COMPLETE (E,EA,IA,SP)
A-4726-025-A VIDEO BOARD, COMPLETE (TW)
A-4726-027-A VIDEO BOARD, COMPLETE (TH)
A-4726-071-A VIDEO BOARD, COMPLETE (E91)
*****************************
< CAPACITOR >
C101 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C102 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C103 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C201 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C202 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C203 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C304 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C305 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C306 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C307 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C308 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C309 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C310 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C311 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C312 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C313 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C314 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C315 1-163-255-11 CERAMIC CHIP 150PF 5% 50V
C316 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C317 1-126-193-11 ELECT 1uF 20% 50V
C318 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C319 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C320 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C321 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C322 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C323 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C324 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C325 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C401 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C402 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C504 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C505 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C506 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C507 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C508 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C509 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C510 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C531 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C532 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C535 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C536 1-126-193-11 ELECT 1uF 20% 50V
C537 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C539 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C540 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C541 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C542 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C543 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C544 1-165-319-11 CERAMIC CHIP 0.1uF 50V
SUB TRANS
TRANS
The components identified by mark 0 or
dotted line with mark 0 are critical for
safety.
Replace only with part number specified.
VIDEO
To Next Page
