Sony HCD-VX333 - Page 20

20
HCD-VX333
• WAVEFORMS
1 IC102 wf (X OUT)
4.1Vp-p
2 IC401 qd (X OUT)
3 IC401 qa (X OUT)
4.0Vp-p
3.0Vp-p
222ns
(4.5MHz)
63ns
(16.0MHz)
31 µ s
(32.768kHz)
1 IC701 4 (X 2)
5.3Vp-p
200ns
(5MHz)
– MAIN BOARD –– PANEL BOARD –
4 IC101 wg (MDP)
2 IC101 ra
(TE)(CD Play mode)
1 IC101 t;
(RFAC)(CD Play mode)
3 IC101 el
(FE)(CD Play mode)
2.6 Vp-p
15.1
µ s
0.2 Vp-p
0.5 Vp-p
1.3 Vp-p
– BD BOARD –
4 J301 3 (COUT)
9 IC505 <z/n (VCK-IN)
7 IC505 od (VSYNC)
8 IC505 <z/z> (HSYNC)
3 J301 4 (YOUT)
1 IC502 qd (XOUT)
37 nsec
4.6 Vp-p
10 MHz
3.5 Vp-p
20 ms
3.2 Vp-p
64 µ s
2.0 Vp-p
H
H
2.0 Vp-p
5.4 Vp-p
2 IC502 wh (BGP)
5 CN301 2 (VIDEO OUT)
6 IC505 ih (DA-XCLK)
3.6 Vp-p
17 MHz
q; IC505 <z/, (DA-LRCK)
qa IC505 <zzz> (DA-BCK)
qs IC509 w; (384FSO)
qd IC509 wf (XT2)
qf IC509 4 (MCKO)
4.5 Vp-p
H
1.3 Vp-p
H
4.5 Vp-p
22.7
µ s
4.5 Vp-p
472 ns
5.0 Vp-p
59 ns
2.0 Vp-p
37 ns
5.2 Vp-p
37 ns
– VIDEO CD BOARD –
