Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
70
HCD-VX333
R507 1-216-073-00 RES-CHIP 10K 5% 1/10W
R508 1-216-073-00 RES-CHIP 10K 5% 1/10W
R516 1-216-073-00 RES-CHIP 10K 5% 1/10W
R517 1-216-073-00 RES-CHIP 10K 5% 1/10W
R518 1-216-073-00 RES-CHIP 10K 5% 1/10W
R519 1-216-025-11 RES-CHIP 100 5% 1/10W
R520 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R521 1-216-073-00 RES-CHIP 10K 5% 1/10W
R523 1-216-013-00 METAL CHIP 33 5% 1/10W
R530 1-216-025-11 RES-CHIP 100 5% 1/10W
R531 1-216-025-11 RES-CHIP 100 5% 1/10W
R532 1-216-295-00 SHORT 0
R533 1-216-295-00 SHORT 0
R534 1-216-073-00 RES-CHIP 10K 5% 1/10W
R535 1-216-073-00 RES-CHIP 10K 5% 1/10W
R536 1-216-033-00 METAL CHIP 220 5% 1/10W
R537 1-216-025-11 RES-CHIP 100 5% 1/10W
R538 1-216-073-00 RES-CHIP 10K 5% 1/10W
R539 1-216-295-00 SHORT 0
R540 1-216-295-00 SHORT 0
R542 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R543 1-216-685-11 METAL CHIP 27K 0.5% 1/10W
R544 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R545 1-216-025-11 RES-CHIP 100 5% 1/10W
R546 1-216-049-11 RES-CHIP 1K 5% 1/10W
R548 1-216-049-11 RES-CHIP 1K 5% 1/10W
R549 1-216-025-11 RES-CHIP 100 5% 1/10W
R550 1-216-025-11 RES-CHIP 100 5% 1/10W
R551 1-216-025-11 RES-CHIP 100 5% 1/10W
R552 1-216-025-11 RES-CHIP 100 5% 1/10W
R555 1-216-121-11 RES-CHIP 1M 5% 1/10W
R556 1-216-025-11 RES-CHIP 100 5% 1/10W
R557 1-216-025-11 RES-CHIP 100 5% 1/10W
R560 1-216-653-11 METAL CHIP 1.2K 0.5% 1/10W
R561 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R562 1-216-073-00 RES-CHIP 10K 5% 1/10W
R563 1-216-073-00 RES-CHIP 10K 5% 1/10W
R577 1-216-081-00 METAL CHIP 22K 5% 1/10W
R578 1-216-081-00 METAL CHIP 22K 5% 1/10W
R579 1-216-073-00 RES-CHIP 10K 5% 1/10W
R580 1-216-073-00 RES-CHIP 10K 5% 1/10W
< VIBRATOR >
X501 1-767-510-11 VIBRATOR, CERAMIC (10MHz)
X503 1-767-519-11 VIBRATOR, CRYSTAL (27MHz)
************************************************************
1-681-441-11 VIDEO OUT BOARD
****************
< CONNECTOR >
CN714 1-564-505-11 PLUG, CONNECTOR 2P
< JACK >
JK705 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
************************************************************
MISCELLANEOUS
*************
14 1-792-246-11 WIRE (FLAT TYPE) (23 CORE)
64 1-796-124-11 DECK, MECH
101 1-773-049-11 WIRE (FLAT TYPE) (17 CORE)
104 1-769-986-11 WIRE (FLAT TYPE) (13 CORE)
0108 1-777-071-81 CORD, POWER (EA,MY,SP,TW)
0108 1-791-901-11 CORD, POWER (E,IA,JE,TH)
259 1-791-983-11 WIRE (FLAT TYPE) (8 CORE)
266 1-471-035-11 MAGNET ASSY
0286 8-820-116-01 OPTICAL PICK-UP KSM-213DCP/Z-NP
288 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
FLD1 1-518-729-11 INDICATOR TUBE, FLUORESCENT
M721 A-4672-826-A MOTOR ASSY (TURN)
M961 1-763-072-11 FAN, DC
0T911 1-437-222-11 TRANSFORMER, POWER (E,EA,IA,JE,MY,SP,TW)
0T911 1-437-228-11 TRANSFORMER, POWER (TH)
************************************************************
HARDWARE LIST
***************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-871-01 SCREW +BVTT 3X6 (S)
#3 7-685-880-09 SCREW +BVTT 4X6 (S)
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#5 7-685-872-09 SCREW +BVTT 3X8 (S)
#6 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
VIDEO OUT
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
