• VIDEO BOARD IC505 CL680T-D1 (MPEG VIDEO/AUDIO DECODER, VIDEO SIGNAL PROCESSOR)
Pin No. Pin Name I/O Description
1NCO
Not used (open)
2 VSS —
Ground terminal
3 CD-BCK I
CD decode bit clock signal (2.8224 MHz) input from the CXD3008Q (IC101)
4 CD-DATA I
CD decode data input from the CXD3008Q (IC101)
5 CD-LRCK I
CD decode L/R sampling clock signal (44.1 kHz) input from the CXD3008Q (IC101)
6 CD-C2PO I
CD decode C2 error data input from the CXD3008Q (IC101)
7 to 9 NC O
Not used (open)
10 to 15 MD0 to MD5 I/O
Two-way data bus with the D-RAM (IC507) Data input from the program ROM (IC506)
16 VSS —
Ground terminal
17 MD6 I/O
Two-way data bus with the D-RAM (IC507) Data input from the program ROM (IC506)
18 VDD3 —
Power supply terminal (+3.3V)
19 MD7 I/O
Two-way data bus with the D-RAM (IC507) Data input from the program ROM (IC506)
20 VSS —
Ground terminal
21 MD8 I/O
Two-way data bus with the D-RAM (IC507) Data output to the program ROM (IC506)
22 VDD3 —
Power supply terminal (+3.3V)
23 to 28 MD9 to MD14 I/O
Two-way data bus with the D-RAM (IC507) Data output to the program ROM (IC506)
29 MD15 I/O
Two-way data bus with the D-RAM (IC507)
30 to 36 NC O
Not used (open)
37 MCE O
Chip enable signal output to the program ROM (IC506)
38 MWE O
Write enable signal output to the D-RAM (IC507)
39 VSS —
Ground terminal
40 CAS O
Column address strobe signal output to the D-RAM (IC507)
41 VDD3 —
Power supply terminal (+3.3V)
42 RAS0 O
Row address strobe signal output to the D-RAM (IC507)
43 RAS1 O
Row address strobe signal output terminal Not used (open)
44, 45 MA10, MA9 O
Address signal output to the program ROM (IC506)
46 MA8 O
Address signal output to the program ROM (IC506) and D-RAM (IC507)
47 VSS —
Ground terminal
48 MA7 O
Address signal output to the program ROM (IC506) and D-RAM (IC507)
49 VDD3 —
Power supply terminal (+3.3V)
50 to 52 MA6 to MA4 O
Address signal output to the program ROM (IC506) and D-RAM (IC507)
53 VSS —
Ground terminal
54 MA3 O
Address signal output to the program ROM (IC506) and D-RAM (IC507)
55 VDD3 —
Power supply terminal (+3.3V)
56 to 58 MA2 to MA0 O
Address signal output to the program ROM (IC506) and D-RAM (IC507)
59 PGIO7 I/O
Not used (open)
60 RESET I
Reset signal input from the CD mechanism controller (IC502) “L”: reset
61 VDDMAX-IN I
Fix the maximum input voltage each input terminal and in/out terminal
62 to 64 NC O
Not used (open)
65 AGND-DAC —
Ground terminal (for D/A converter)
66 AVDD-DAC —
Power supply terminal (+3.3V) (for D/A converter)
67 COMPOS OUT O
Composite video signal output terminal Not used (open)
68 AGND-DAC —
Ground terminal (for D/A converter)
69 Y-OUT O
Luminance video signal output terminal
70 AVDD-DAC —
Power supply terminal (+3.3V) (for D/A converter)
71 AGND-DAC —
Ground terminal (for D/A converter)
