13
HCD-WZ8D
2-12. Pick-up Unit (TDP022W)
3
w
ire (flat type)
24p (CN001)
2
flexible board
(CN003)
5
three step screws (M)
8
pick-up unit (TDP022W)
1
claw
6
holder (DBU1)
7
three insulators
4
RF board
