HCD-WZ8D
2-2. Front Panel Assy
2-3. PANEL Board, CD-TC-SW Board, ENTER-SW Board, BACK LIGHT Board, LCD Board
qa front panel
section
9 connector
(CN108)
3 loading panel
How to eject the disc tray when the
main power cannot be turned on.
1
2
q;
wire (flat type)
(23 core) (CN109)
6 three screws
(+BVTP 3
× 8)
4 screw
(+BVTP 3
× 8)
5 wire
(NO601)
8
7
claw
bottom side
5 two claws
qh three claws
qf PANEL board
qs ENTER-SW board
7 CD-TC SW board
qj BACK LIGHT board
w; LCD board
wa LCD assy
ql Remove the soldering.
qd wire (flat type)
(23 core) (CN605)
8 eight screws
(+BVTP 2.6
× 8)
qa two screws
(+BVTP 2.6
× 8)
qg four screws
(+BVTP 2.6
× 8)
qk two screws
(+BVTP 2.6
× 8)
9 connector
(CN602)
q; connector
(CN603)
6 connector
(CN604)
4 two screws
(+BVTP 2.6
× 8
)
1 knob (volume)
3 button (cursor)
2 nut
