Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
•-XX, -X mean standardized parts, so they may
have some difference from the original one.
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• CAPACITORS:
uF: µF
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
•Abbreviation
AUS: Australian model
E2 : 120V AC area in E model
E3 : 240V AC area in E model
E15 : 220-240V AC area in E model
EA : Saudi Arabia model
KR : Korean model
MY : Malaysia model
PH : Philippines model
RU : Russian model
SP : Singapore model
TH : Thai model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
A-4732-203-A 4CH-VOL BOARD, COMPLETE (AEP, UK, RU)
************************
A-4732-217-A 4CH-VOL BOARD, COMPLETE (E2)
************************
A-4732-323-A 4CH-VOL BOARD, COMPLETE
(E3, E15, EA, MY, SP, KR, PH)
************************
A-4732-332-A 4CH-VOL BOARD, COMPLETE (AUS)
************************
A-4734-603-A 4CH-VOL BOARD, COMPLETE (TH)
************************
< CAPACITOR >
C301 1-126-964-11 ELECT 10uF 20.00% 50V
C302 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C303 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C304 1-126-964-11 ELECT 10uF 20.00% 50V
C305 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C306 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C307 1-126-964-11 ELECT 10uF 20.00% 50V
C308 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C309 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C310 1-126-964-11 ELECT 10uF 20.00% 50V
C311 1-126-964-11 ELECT 10uF 20.00% 50V
C312 1-126-964-11 ELECT 10uF 20.00% 50V
C315 1-126-964-11 ELECT 10uF 20.00% 50V
C316 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C320 1-126-964-11 ELECT 10uF 20.00% 50V
C321 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C322 1-126-964-11 ELECT 10uF 20.00% 50V
C323 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C324 1-126-964-11 ELECT 10uF 20.00% 50V
C325 1-126-964-11 ELECT 10uF 20.00% 50V
C330 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C331 1-126-964-11 ELECT 10uF 20.00% 50V
C332 1-136-169-00 FILM 0.22uF 5.00% 50V
C333 1-136-165-00 FILM 0.1uF 5.00% 50V
C334 1-126-964-11 ELECT 10uF 20.00% 50V
C337 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C341 1-126-933-11 ELECT 100uF 20.00% 16V
C342 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C343 1-126-960-11 ELECT 1uF 20.00% 50V
C344 1-126-933-11 ELECT 100uF 20.00% 16V
C345 1-126-935-11 ELECT 470uF 20.00% 16V
C346 1-164-360-11 CERAMIC CHIP 0.1uF 16V
(AEP, UK, RU, AUS)
C347 1-164-360-11 CERAMIC CHIP 0.1uF 16V
(AEP, UK, RU, AUS)
C348 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C351 1-126-964-11 ELECT 10uF 20.00% 50V
C352 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C353 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C354 1-126-964-11 ELECT 10uF 20.00% 50V
C355 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C356 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C357 1-126-964-11 ELECT 10uF 20.00% 50V
C358 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C359 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C360 1-126-964-11 ELECT 10uF 20.00% 50V
C361 1-126-964-11 ELECT 10uF 20.00% 50V
C362 1-126-964-11 ELECT 10uF 20.00% 50V
C365 1-126-964-11 ELECT 10uF 20.00% 50V
C366 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C370 1-126-964-11 ELECT 10uF 20.00% 50V
C371 1-126-964-11 ELECT 10uF 20.00% 50V
C372 1-126-964-11 ELECT 10uF 20.00% 50V
C373 1-126-964-11 ELECT 10uF 20.00% 50V
C374 1-126-964-11 ELECT 10uF 20.00% 50V
C375 1-126-964-11 ELECT 10uF 20.00% 50V
C376 1-126-964-11 ELECT 10uF 20.00% 50V
C377 1-126-964-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
CN301 1-784-786-11 CONNECTOR, FFC 25P (AEP, UK, RU, AUS)
CN301 1-784-784-11 CONNECTOR, FFC 23P
(EXCEPT AEP, UK, RU, AUS)
* CN302 1-566-460-11 PIN, CONNECTOR 4P
CN303 1-779-293-11 CONNECTOR, FFC (LIF (NON-ZIF)) 25P
(AEP, UK, RU, AUS)
CN303 1-779-289-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
(EXCEPT AEP, UK, RU, AUS)
< IC >
IC301 6-703-651-11 IC M61530FP-D60G
< JACK >
J302 1-770-377-31 JACK, PIN 1P 9 (SUB WOOFER OUT)
< COIL >
L341 1-412-064-11 INDUCTOR 100uH
4CH-VOL
