67
HCD-WZ8D
Pin No.
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
I/O
O
O
I
I
O
O
O
O
I
O
O
—
I
—
O
O
I
I
O
O
O
O
I
I
O
O
O
O
O
O
O
O
O
O
O
O
I
I
I
I
O
O
I
I
I
—
I
—
—
O
Pin Name
VOL-CLK
VOL-DATA
CN CHECK
AMS-IN
TC LINE-MUTE
ALC
TC REC-MUTE
IO-EXP DATA OUT
IO-EXP DATA IN
IO-EXP LAT
IO-EXP CLK
VCC
HEAD-PHONE IN
VSS
STK MUTE
TA MUTE
VOL-A
VOL-B
LED -TUNER/BAND
LED-DVD
LED-AROUND PLAY
LED-TAPE A/B
DISPLAY KEY
POWER KEY
LED-MD (VIDEO)
LED-STANDBY
HP/REC OUT MUTE
BACK-LIGHT 3
BACK-LIGHT 2
BACK-LIGHT 1
LCD-DATA
LCD-CLK
LCD-ENB
LCD-RS
LOAD-OUT
LOAD-IN
OPEN-SW
CLOSE-SW
A SHUT
B SHUT
A TRG
B TRG
SPEC-IN
AD-KEY2
AD-KEY1
AVSS
VA CS IN
VREF
AVCC
LCD RESET
Description
Clock output to the audio signal processor (IC101)
Data output to the audio signal processor (IC101)
Connection check signal input (from DXA-WZ8D)
AMS signal input (“L” : in, “H” : off)(from DXA-WZ8D)
TC line muting signal output (“H” : on, “L” : off)(to DXA-WZ8D)
ALC signal output (“L” : on, “H” : off)(to DXA-WZ8D)
TC REC muting signal output (“L” : on, “H” : off)(to DXA-WZ8D)
Data output to the I/O expander (IC251, DXA-WZ8D)
Data input from the I/O expander (IC251, DXA-WZ8D)
Latch signal output to the I/O expander (IC251, DXA-WZ8D)
Clock output to the I/O expander (IC251, DXA-WZ8D)
Power supply terminal
Headphone detection signal input
Ground terminal
Muting signal output to the power amplifier (to DXA-WZ8D)
TA line muting signal output (“H” : on, “L” : off)(to DXA-WZ8D)
Encoder signal input from the volume encoder
Encoder signal input from the volume encoder
TUNER/BAND LED control signal output
DVD LED control signal output
PLAY LED control signal output
TAPE A/B LED control signal output
DISPLAY key signal input
POWER key signal input
MD (VIDEO) LED control signal output
STANDBY LED control signal output
Headphone/line out muting signal output (“L” : on, “H” : off)
LCD back light 3 LED control signal output (blue)
LCD back light 2 LED control signal output (green)
LCD back light 1 LED control signal output (red)
Data output to the liquid crystal display
Clock output to the liquid crystal display
Chip select signal output to the liquid crystal display
Reset signal output to the liquid crystal display
Loading motor control signal output
Loading motor control signal output
OPEN switch signal input
CLOSE switch signal input
Reel pulse signal input from the deck A (from DXA-WZ8D)
Reel pulse signal input from the deck B (from DXA-WZ8D)
Trigger control signal output to the deck A (“H” : on)(to DXA-WZ8D)
Trigger control signal output to the deck B (“H” : on)(to DXA-WZ8D)
Spec setting terminal
Key input 2 (A/D)
Key input 1 (A/D)
Ground terminal (A/D converter)
VA CS signal input
Voltage reference terminal (A/D converter)
Power supply terminal (A/D converter)
Reset signal output to the liquid crystal display
