79
HCD-WZ8D
FL602 1-234-177-21 FERRITE 0uH
(E3, E15, EA, MY, SP, TH, KR, PH, AUS)
FL701 1-234-177-21 FERRITE 0uH
FL702 1-234-177-21 FERRITE 0uH
FL703 1-234-177-21 FERRITE 0uH
FL704 1-234-177-21 FERRITE 0uH
FL705 1-234-177-21 FERRITE 0uH
FL706 1-234-177-21 FERRITE 0uH
FL901 1-234-177-21 FERRITE 0uH
FL903 1-234-177-21 FERRITE 0uH
FL908 1-234-177-21 FERRITE 0uH
< IC >
IC203 6-705-034-01 IC HY57V283220T-6
* IC204 6-703-671-01 IC BR9040F-WE2
IC206 6-803-555-01 IC MBM29DL324BE-90PFTN-SB3V107
IC207 6-703-540-01 IC ZIVA5X-C1F
IC211 6-700-398-01 IC uPC2918T-E1
IC216 6-700-437-01 IC SN74ALVCH16841DGGR
IC252 8-759-680-48 IC TC7WH157FK (TE85R)(AEP, UK, RU, AUS)
IC255 8-759-058-54 IC TC7S00FU (TE85R)
IC256 8-759-549-21 IC SN74LV573APWR
IC258 8-759-549-21 IC SN74LV573APWR
IC259 8-759-549-21 IC SN74LV573APWR
IC302 6-703-787-01 IC PCM1609KPTR
IC352 8-759-560-56 IC PCM1800E/2K
IC392 8-759-583-47 IC uPC2933T-E2
IC393 6-700-394-01 IC BA25BC0FP-E2
(E3, E15, EA, MY, SP, TH, KR, PH, AUS)
IC501 6-702-157-01 IC FAN8035L
IC503 8-759-058-43 IC NJM3404AV (TE2)
IC509 8-752-408-73 IC CXD3068Q
IC601 6-704-421-01 IC CXD9782R
(E3, E15, EA, MY, SP, TH, KR, PH, AUS)
IC602 8-759-538-16 IC IS61LV6416-10TT (ISSI)
(E3, E15, EA, MY, SP, TH, KR, PH, AUS)
IC701 6-703-552-01 IC CXD1882R
IC701 6-703-552-01 IC CXD1882R (AEP)
IC703 8-759-058-43 IC NJM3404AV (TE2)
IC706 8-759-564-30 IC MSM51V18165F-60TSKR1
IC901 8-752-937-54 IC CXP973064-228R
IC902 8-759-058-64 IC TC7S32FU-TE85L
IC903 8-759-641-86 IC BR24C16F-E2
IC904 6-702-563-01 IC TC7W74FK-TE85L
IC906 6-700-407-01 IC SM8707GV-G-E2
IC907 8-759-583-47 IC uPC2933T-E2
< JUMPER RESISTOR >
JW392 1-216-864-11 METAL CHIP 0 5% 1/10W
JW601 1-218-990-11 SHORT CHIP 0 (AEP, UK, RU, E2)
JW602 1-218-990-11 SHORT CHIP 0 (AEP, UK, RU, E2)
JW603 1-218-990-11 SHORT CHIP 0 (AEP, UK, RU, E2)
JW604 1-218-990-11 SHORT CHIP 0 (AEP, UK, RU, E2)
JW605 1-218-990-11 SHORT CHIP 0 (AEP, UK, RU, E2)
JW606 1-218-990-11 SHORT CHIP 0 (AEP, UK, RU, E2)
JW607 1-218-990-11 SHORT CHIP 0 (AEP, UK, RU, E2)
JW801 1-218-990-11 SHORT CHIP 0
JW802 1-218-990-11 SHORT CHIP 0
JW803 1-218-990-11 SHORT CHIP 0
JW804 1-218-990-11 SHORT CHIP 0
JW805 1-218-990-11 SHORT CHIP 0
JW806 1-218-990-11 SHORT CHIP 0
< COIL >
L402 1-216-296-11 SHORT CHIP 0
L403 1-216-296-11 SHORT CHIP 0
L404 1-216-296-11 SHORT CHIP 0
L405 1-216-296-11 SHORT CHIP 0
L406 1-216-296-11 SHORT CHIP 0
L412 1-216-296-11 SHORT CHIP 0
L413 1-216-296-11 SHORT CHIP 0
L414 1-216-296-11 SHORT CHIP 0
L415 1-216-296-11 SHORT CHIP 0
L416 1-216-296-11 SHORT CHIP 0
L901 1-412-031-11 INDUCTOR CHIP 47uH
< TRANSISTOR >
Q202 8-729-929-26 TRANSISTOR DTC114TE-TL
Q901 8-729-929-26 TRANSISTOR DTC114TE-TL
Q903 8-729-025-28 TRANSISTOR 2SK1828TE85L
Q904 8-729-025-28 TRANSISTOR 2SK1828TE85L
< RESISTOR >
R10 1-216-801-11 METAL CHIP 22 5% 1/10W
R11 1-216-801-11 METAL CHIP 22 5% 1/10W
R12 1-216-801-11 METAL CHIP 22 5% 1/10W
R13 1-216-801-11 METAL CHIP 22 5% 1/10W
R14 1-216-801-11 METAL CHIP 22 5% 1/10W
R15 1-216-801-11 METAL CHIP 22 5% 1/10W
R197 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R198 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R207 1-216-864-11 METAL CHIP 0 5% 1/10W
R213 1-216-807-11 METAL CHIP 68 5% 1/10W
R214 1-216-864-11 METAL CHIP 0 5% 1/10W
R215 1-216-864-11 METAL CHIP 0 5% 1/10W
R217 1-216-864-11 METAL CHIP 0 5% 1/10W
R218 1-216-864-11 METAL CHIP 0 5% 1/10W
R219 1-216-864-11 METAL CHIP 0 5% 1/10W
R220 1-216-864-11 METAL CHIP 0 5% 1/10W
R221 1-216-864-11 METAL CHIP 0 5% 1/10W
R222 1-216-864-11 METAL CHIP 0 5% 1/10W
R223 1-216-864-11 METAL CHIP 0 5% 1/10W
R224 1-216-864-11 METAL CHIP 0 5% 1/10W
R225 1-216-864-11 METAL CHIP 0 5% 1/10W
R226 1-216-864-11 METAL CHIP 0 5% 1/10W
R227 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R228 1-216-864-11 METAL CHIP 0 5% 1/10W
R230 1-216-803-11 METAL CHIP 33 5% 1/10W
R231 1-216-803-11 METAL CHIP 33 5% 1/10W
R232 1-216-803-11 METAL CHIP 33 5% 1/10W
R233 1-216-864-11 METAL CHIP 0 5% 1/10W
R234 1-216-833-11 METAL CHIP 10K 5% 1/10W
R239 1-216-809-11 METAL CHIP 100 5% 1/10W
(AEP, UK, RU, AUS)
R240 1-216-841-11 METAL CHIP 47K 5% 1/10W
R241 1-216-864-11 METAL CHIP 0 5% 1/10W
R243 1-216-864-11 METAL CHIP 0 5% 1/10W
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
DMB03
