73
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR99AV
PA
< JACK >
J801 1-770-226-11 JACK (LARGE TYPE) (MIC-2)
J802 1-770-226-11 JACK (LARGE TYPE) (MIC-1)
< TRANSISTOR >
Q884 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R806 1-249-429-11 CARBON 10K 5% 1/4W
R807 1-249-429-11 CARBON 10K 5% 1/4W
R808 1-249-417-11 CARBON 1K 5% 1/4W F
R809 1-249-417-11 CARBON 1K 5% 1/4W F
R811 1-249-441-11 CARBON 100K 5% 1/4W
R850 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-441-11 CARBON 100K 5% 1/4W
R853 1-249-417-11 CARBON 1K 5% 1/4W F
R854 1-249-437-11 CARBON 47K 5% 1/4W
R855 1-249-429-11 CARBON 10K 5% 1/4W
R856 1-247-899-11 CARBON 680K 5% 1/4W
R857 1-249-425-11 CARBON 4.7K 5% 1/4W F
R874 1-249-431-11 CARBON 15K 5% 1/4W
R876 1-249-417-11 CARBON 1K 5% 1/4W F
R877 1-249-411-11 CARBON 330 5% 1/4W
R878 1-249-417-11 CARBON 1K 5% 1/4W F
R879 1-249-417-11 CARBON 1K 5% 1/4W F
******************************************************
*
A-4673-765-A MOTOR BOARD, COMPLETE
********************
*
4-980-385-01 HOLDER (SW)
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-164-159-21 CERAMIC 0.1uF 50V
C203 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN201 1-568-947-11 PIN, CONNECTOR 9P
< IC >
IC201 8-759-365-94 IC TA8409S
< COIL >
L201 1-408-117-00 INDUCTOR 10uH
< RESISTOR >
R205 1-249-427-11 CARBON 6.8K 5% 1/4W F
R206 1-249-425-11 CARBON 4.7K 5% 1/4W F
< SWITCH >
S201 1-762-587-11 SWITCH, PUSH (1 KEY) (UP)
******************************************************
A-4732-077-A PA BOARD, COMPLETE
*****************
4-875-327-31 HEAT SINK
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C401 1-126-963-11 ELECT 4.7uF 20% 50V
C406 1-164-159-11 CERAMIC 0.1uF 50V
C407 1-164-159-11 CERAMIC 0.1uF 50V
C408 1-164-159-11 CERAMIC 0.1uF 50V
C409 1-164-159-11 CERAMIC 0.1uF 50V
C410 1-164-159-11 CERAMIC 0.1uF 50V
C411 1-164-159-11 CERAMIC 0.1uF 50V
C412 1-162-306-11 CERAMIC 0.01uF 30% 16V
C413 1-162-306-11 CERAMIC 0.01uF 30% 16V
C414 1-162-306-11 CERAMIC 0.01uF 30% 16V
C415 1-162-306-11 CERAMIC 0.01uF 30% 16V
C416 1-162-306-11 CERAMIC 0.01uF 30% 16V
C801 1-128-582-11 ELECT 10uF 20% 100V
C802 1-162-290-31 CERAMIC 470PF 10% 50V
C803 1-162-286-31 CERAMIC 220PF 10% 50V
C804 1-126-965-91 ELECT 22uF 20% 50V
C807 1-128-560-11 ELECT 22uF 20% 100V
C808 1-137-749-11 MYLAR 0.1uF 100V
C809 1-137-749-11 MYLAR 0.1uF 100V
C810 1-128-562-11 ELECT 47uF 20% 100V
C811 1-130-491-00 MYLAR 0.047uF 5% 50V
C812 1-130-491-00 MYLAR 0.047uF 5% 50V
C813 1-162-306-11 CERAMIC 0.01uF 30% 16V
C814 1-162-294-31 CERAMIC 0.001uF 10% 50V
C815 1-126-959-11 ELECT 0.47uF 20% 50V
C830 1-107-714-11 ELECT 10uF 20% 50V
C831 1-126-964-11 ELECT 10uF 20% 50V
C832 1-126-967-91 ELECT 47uF 20% 50V
C833 1-126-964-11 ELECT 10uF 20% 50V
C841 1-127-751-11 ELECT 3300uF 20% 50V
C842 1-127-815-11 ELECT 3300uF 20% 100V
C844 1-137-749-11 MYLAR 0.1uF 100V
C845 1-126-943-11 ELECT 2200uF 20% 25V
C847 1-164-159-11 CERAMIC 0.1uF 50V
C848 1-164-159-11 CERAMIC 0.1uF 50V
C849 1-164-159-11 CERAMIC 0.1uF 50V
C850 1-107-721-11 ELECT 4.7uF 20% 100V
C851 1-128-582-11 ELECT 10uF 20% 100V
C852 1-162-290-31 CERAMIC 470PF 10% 50V
C853 1-162-286-31 CERAMIC 220PF 10% 50V
C854 1-126-965-91 ELECT 22uF 20% 50V
C857 1-128-560-11 ELECT 22uF 20% 100V
C858 1-164-159-11 CERAMIC 0.1uF 50V
C859 1-164-159-11 CERAMIC 0.1uF 50V
C861 1-130-491-00 MYLAR 0.047uF 5% 50V
C862 1-130-491-00 MYLAR 0.047uF 5% 50V
C863 1-126-961-11 ELECT 2.2uF 20% 50V
C864 1-104-665-11 ELECT 100uF 20% 25V
C891 1-127-751-11 ELECT 3300uF 20% 50V
C892 1-127-815-11 ELECT 3300uF 20% 100V
C894 1-137-749-11 MYLAR 0.1uF 100V
C895 1-107-721-11 ELECT 4.7uF 20% 100V
C902 1-164-159-11 CERAMIC 0.1uF 50V
C903 1-126-933-11 ELECT 100uF 20% 16V
C904 1-126-964-11 ELECT 10uF 20% 50V
