74
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR99AV
PA
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
C905 1-126-968-11 ELECT 100uF 20% 50V
C906 1-126-943-11 ELECT 2200uF 20% 25V
C909 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN803 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN804 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
* CN806 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN904 1-785-316-11 PIN, CONNECTOR (STRAIGHT) 4P
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-991-33 DIODE 1SS133T-77
D403 8-719-991-33 DIODE 1SS133T-77
D404 8-719-991-33 DIODE 1SS133T-77
D405 8-719-991-33 DIODE 1SS133T-77
D406 8-719-991-33 DIODE 1SS133T-77
D407 8-719-991-33 DIODE 1SS133T-77
D408 8-719-991-33 DIODE 1SS133T-77
D409 8-719-991-33 DIODE 1SS133T-77
D410 8-719-991-33 DIODE 1SS133T-77
D801 8-719-991-33 DIODE 1SS133T-77
D802 8-719-110-48 DIODE RD18ESB1
D803 8-719-991-33 DIODE 1SS133T-77
D804 8-719-991-33 DIODE 1SS133T-77
D805 8-719-991-33 DIODE 1SS133T-77
D831 8-719-510-68 DIODE D5SBA204101
D833 6-500-522-11 DIODE 10EDB40-TA2B5
D834 6-500-522-11 DIODE 10EDB40-TA2B5
D835 6-500-522-11 DIODE 10EDB40-TA2B5
D836 6-500-522-11 DIODE 10EDB40-TA2B5
D841 6-500-522-11 DIODE 10EDB40-TA2B5
D842 6-500-522-11 DIODE 10EDB40-TA2B5
D843 6-500-522-11 DIODE 10EDB40-TA2B5
D844 6-500-522-11 DIODE 10EDB40-TA2B5
D851 8-719-991-33 DIODE 1SS133T-77
D852 8-719-110-48 DIODE RD18ESB1
D853 8-719-991-33 DIODE 1SS133T-77
D902 6-500-522-11 DIODE 10EDB40-TA2B5
D903 6-500-522-11 DIODE 10EDB40-TA2B5
D904 6-500-522-11 DIODE 10EDB40-TA2B5
D905 6-500-522-11 DIODE 10EDB40-TA2B5
D911 8-719-983-86 DIODE MTZJ-T-72-33A
D912 8-719-109-89 DIODE RD5.6ESB2
< IC >
IC801 8-749-017-06 IC STK412-150
IC901 6-701-760-01 IC uPC3504AHF
< COIL >
L403 1-422-009-13 COIL, AIR-CORE
L404 1-422-009-13 COIL, AIR-CORE
L405 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q401 8-729-029-40 TRANSISTOR DTA124ESA
Q402 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q403 8-729-029-40 TRANSISTOR DTA124ESA
Q407 8-729-029-86 TRANSISTOR DTC124ESA
Q431 8-729-620-05 TRANSISTOR 2SC2603-EF
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q803 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q804 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q805 8-729-231-55 TRANSISTOR 2SC2878-AB
Q831 8-729-029-86 TRANSISTOR DTC124ESA
Q832 8-729-620-05 TRANSISTOR 2SC2603-EF
Q833 8-729-029-40 TRANSISTOR DTA124ESA
Q834 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q842 8-729-620-05 TRANSISTOR 2SC2603-EF
Q843 8-729-029-86 TRANSISTOR DTC124ESA
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q855 8-729-231-55 TRANSISTOR 2SC2878-AB
Q901 8-729-620-05 TRANSISTOR 2SC2603-EF
Q903 8-729-209-60 TRANSISTOR 2SB1375
Q908 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
0R401 1-216-430-11 METAL OXIDE 390 5% 1W
0R402 1-216-452-11 METAL OXIDE 180 5% 2W
R406 1-249-437-11 CARBON 47K 5% 1/4W
R407 1-249-437-11 CARBON 47K 5% 1/4W
R408 1-249-440-11 CARBON 82K 5% 1/4W
R409 1-249-437-11 CARBON 47K 5% 1/4W
R416 1-249-389-11 CARBON 4.7 5% 1/4W F
R417 1-249-389-11 CARBON 4.7 5% 1/4W F
R418 1-249-389-11 CARBON 4.7 5% 1/4W F
R419 1-249-389-11 CARBON 4.7 5% 1/4W F
R420 1-249-389-11 CARBON 4.7 5% 1/4W F
R421 1-249-389-11 CARBON 4.7 5% 1/4W F
R422 1-260-076-11 CARBON 10 5% 1/2W
R423 1-260-076-11 CARBON 10 5% 1/2W
R424 1-260-076-11 CARBON 10 5% 1/2W
R425 1-249-437-11 CARBON 47K 5% 1/4W
R429 1-249-437-11 CARBON 47K 5% 1/4W
R431 1-249-438-11 CARBON 56K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R439 1-249-425-11 CARBON 4.7K 5% 1/4W F
R442 1-249-435-11 CARBON 33K 5% 1/4W
R443 1-249-434-11 CARBON 27K 5% 1/4W
R444 1-249-439-11 CARBON 68K 5% 1/4W
R446 1-249-429-11 CARBON 10K 5% 1/4W
R447 1-249-437-11 CARBON 47K 5% 1/4W
R450 1-249-437-11 CARBON 47K 5% 1/4W
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-414-11 CARBON 560 5% 1/4W F
R804 1-249-435-11 CARBON 33K 5% 1/4W
R805 1-216-436-00 METAL OXIDE 3.9K 5% 1W
R806 1-216-436-00 METAL OXIDE 3.9K 5% 1W
0R807 1-212-881-11 FUSIBLE 100 5% 1/4W
0R808 1-219-718-11 METAL 0.1 10% 5W
R809 1-260-076-11 CARBON 10 5% 1/2W
R810 1-249-437-11 CARBON 47K 5% 1/4W
R811 1-249-417-11 CARBON 1K 5% 1/4W F
R812 1-249-431-11 CARBON 15K 5% 1/4W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-249-421-11 CARBON 2.2K 5% 1/4W F
R815 1-249-433-11 CARBON 22K 5% 1/4W
R816 1-249-429-11 CARBON 10K 5% 1/4W
R817 1-249-437-11 CARBON 47K 5% 1/4W
R818 1-249-409-11 CARBON 220 5% 1/4W F
