75
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR99AV
PANEL FL
R819 1-249-439-11 CARBON 68K 5% 1/4W
0R820 1-217-637-00 FUSIBLE 1 5% 1/4W
R821 1-249-435-11 CARBON 33K 5% 1/4W
R822 1-249-433-11 CARBON 22K 5% 1/4W
R823 1-249-433-11 CARBON 22K 5% 1/4W
R824 1-249-421-11 CARBON 2.2K 5% 1/4W F
R825 1-215-891-11 METAL OXIDE 680 5% 2W
R827 1-249-441-11 CARBON 100K 5% 1/4W
R828 1-247-903-00 CARBON 1M 5% 1/4W
R831 1-249-441-11 CARBON 100K 5% 1/4W
R832 1-249-441-11 CARBON 100K 5% 1/4W
R833 1-247-856-00 CARBON 11K 5% 1/4W
R834 1-249-429-11 CARBON 10K 5% 1/4W
R835 1-249-437-11 CARBON 47K 5% 1/4W
R836 1-249-417-11 CARBON 1K 5% 1/4W F
R837 1-249-429-11 CARBON 10K 5% 1/4W
R838 1-249-429-11 CARBON 10K 5% 1/4W
R839 1-249-441-11 CARBON 100K 5% 1/4W
R840 1-249-402-11 CARBON 56 5% 1/4W F
R842 1-249-411-11 CARBON 330 5% 1/4W
R843 1-249-441-11 CARBON 100K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-249-414-11 CARBON 560 5% 1/4W F
R855 1-215-891-11 METAL OXIDE 680 5% 2W
0R857 1-212-881-11 FUSIBLE 100 5% 1/4W
0R858 1-219-718-11 METAL 0.1 10% 5W
R859 1-260-076-11 CARBON 10 5% 1/2W
R860 1-249-437-11 CARBON 47K 5% 1/4W
R861 1-249-417-11 CARBON 1K 5% 1/4W F
R862 1-249-431-11 CARBON 15K 5% 1/4W
R863 1-249-441-11 CARBON 100K 5% 1/4W
R864 1-249-425-11 CARBON 4.7K 5% 1/4W F
R865 1-249-433-11 CARBON 22K 5% 1/4W
R866 1-249-429-11 CARBON 10K 5% 1/4W
R867 1-249-421-11 CARBON 2.2K 5% 1/4W F
R868 1-249-409-11 CARBON 220 5% 1/4W F
R880 1-249-402-11 CARBON 56 5% 1/4W F
0R888 1-219-718-11 METAL 0.1 10% 5W
R889 1-249-441-11 CARBON 100K 5% 1/4W
0R898 1-219-718-11 METAL 0.1 10% 5W
R902 1-249-441-11 CARBON 100K 5% 1/4W
R903 1-249-429-11 CARBON 10K 5% 1/4W
R904 1-249-417-11 CARBON 1K 5% 1/4W F
R905 1-249-429-11 CARBON 10K 5% 1/4W
R906 1-247-807-31 CARBON 100 5% 1/4W
R907 1-247-807-31 CARBON 100 5% 1/4W
R915 1-249-397-11 CARBON 22 5% 1/4W F
0R916 1-215-915-11 METAL OXIDE 470 5% 3W
< RELAY >
RY401 1-515-920-11 RELAY
RY402 1-515-920-11 RELAY (24V)
RY403 1-515-920-11 RELAY (24V)
< THERMISTOR >
TH831 1-807-796-11 THERMISTOR
< TERMINAL >
TM401 1-537-925-61 TERMINAL BOARD (FRONT SPEAKER)
TM402 1-537-510-31 TERMINAL BOARD (SPEAKER) (6P)
(SURROUND/CENTER SPEAKER)
******************************************************
A-4732-037-A PANEL FL BOARD, COMPLETE
**********************
4-225-511-01 HOLDER FL TUBE
4-949-935-41 CUSHION (FL)
< CAPACITOR >
C601 1-162-294-31 CERAMIC 0.001uF 10% 50V
C602 1-126-947-11 ELECT 47uF 20% 16V
C603 1-162-306-11 CERAMIC 0.01uF 30% 16V
C604 1-126-947-11 ELECT 47uF 20% 16V
C605 1-162-306-11 CERAMIC 0.01uF 30% 16V
C606 1-126-963-11 ELECT 4.7uF 20% 50V
C607 1-164-159-11 CERAMIC 0.1uF 50V
C608 1-164-159-11 CERAMIC 0.1uF 50V
C614 1-124-233-91 ELECT 10uF 20% 16V
C615 1-126-964-11 ELECT 10uF 20% 50V
C616 1-162-297-11 CERAMIC 0.0033uF 30% 16V
C617 1-164-159-11 CERAMIC 0.1uF 50V
C618 1-164-159-11 CERAMIC 0.1uF 50V
C619 1-124-233-91 ELECT 10uF 20% 16V
C620 1-162-300-11 CERAMIC 0.01uF 30% 16V
C622 1-126-960-11 ELECT 1uF 20% 50V
C623 1-126-960-11 ELECT 1uF 20% 50V
C624 1-126-947-11 ELECT 47uF 20% 16V
C625 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN601 1-784-741-11 CONNECTOR, FFC 19P
CN602 1-784-780-11 CONNECTOR, FFC 19P
< DIODE >
D601 8-719-991-33 DIODE 1SS133T-77
D602 8-719-058-04 DIODE SEL5223S-TP15 (=/1)
< FLUORESCENT INDICATOR TUBE >
FL601 1-518-794-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 6-802-683-01 IC MB90M407APF-G-125-BND
IC602 8-759-826-34 IC NJL74H400A (SIRCS)
IC603 8-759-570-21 IC BA3830F
< COIL >
L603 1-410-332-31 INDUCTOR 47uH
< TRANSISTOR >
Q601 8-729-029-86 TRANSISTOR DTC124ESA
Q602 8-729-620-05 TRANSISTOR 2SC2603-EF
Q603 8-729-140-04 TRANSISTOR 2SB1116A-L
Q604 8-729-620-05 TRANSISTOR 2SC2603-EF
Q605 8-729-140-04 TRANSISTOR 2SB1116A-L
Q606 8-729-047-58 TRANSISTOR DTC114TLTL2
Q607 8-729-047-58 TRANSISTOR DTC114TLTL2
Q608 8-729-047-58 TRANSISTOR DTC114TLTL2
Q609 8-729-047-58 TRANSISTOR DTC114TLTL2
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
