<EXT SWITCH>
16
RET2 Pin6 OFF, RETURN1 SW, RETURN2
SW, RETURN3 SW, INCOM 1,
INCOM 2, EXTENDER, 5600K,
VF DETAIL, SPIRIT LEVEL,
FOCUS ASSIST, PinP, VF
ASSIGN SW1, VF ASSIGN SW2
JN/SY models only.
This function works when each pin of the RET CTRL
connector contacts with GND (Pin3).
OFF, RETURN1 SW, RETURN2
SW, RETURN3 SW, ENG,
PROD, EXTENDER, 5600K, VF
DETAIL, SPIRIT LEVEL, FOCUS
ASSIST, PinP, VF ASSIGN SW1,
VF ASSIGN SW2
CE/CN models only.
RET3 Pin4 OFF, RETURN1 SW, RETURN2
SW, RETURN3 SW
, INCOM 1,
INCOM 2, EXTENDER, 5600K,
VF DETAIL, SPIRIT LEVEL,
FOCUS ASSIST, PinP, VF
ASSIGN SW1, VF ASSIGN SW2,
TALLY
JN/SY models only.
OFF, RETURN1 SW, RETURN2
SW, RETURN3 SW
, ENG,
PROD, EXTENDER, 5600K, VF
DETAIL, SPIRIT LEVEL, FOCUS
ASSIST, PinP, VF ASSIGN SW1,
VF ASSIGN SW2, TALLY
CE/CN models only.
INCOM1 Pin1 OFF, RETURN1 SW, RETURN2
SW, RETURN3 SW, INCOM 1
,
INCOM 2, EXTENDER, 5600K,
VF DETAIL, SPIRIT LEVEL,
FOCUS ASSIST, PinP, VF
ASSIGN SW1, VF ASSIGN SW2
JN/SY models only.
OFF, RETURN1 SW, RETURN2
SW, RETURN3 SW, ENG
,
PROD, EXTENDER, 5600K, VF
DETAIL, SPIRIT LEVEL, FOCUS
ASSIST, PinP, VF ASSIGN SW1,
VF ASSIGN SW2
CE/CN models only.
INCOM2 Pin2 OFF, RETURN1 SW, RETURN2
SW, RETURN3 SW, INCOM 1,
INCOM 2
, EXTENDER, 5600K,
VF DETAIL, SPIRIT LEVEL,
FOCUS ASSIST, PinP, VF
ASSIGN SW1, VF ASSIGN SW2
JN/SY models only.
OFF, RETURN1 SW, RETURN2
SW, RETURN3 SW, ENG,
PROD
, EXTENDER, 5600K, VF
DETAIL, SPIRIT LEVEL, FOCUS
ASSIST, PinP, VF ASSIGN SW1,
VF ASSIGN SW2
CE/CN models only.
