42
<RETURN>
17
RET1 SW SEL CCU RET1, CCU RET2,
CCU RET3, CCU RET4
Varies based on the RET 1 button setting.
RET2 SW SEL Varies based on the RET 2 button setting.
RET3 SW SEL CCU RET1, CCU RET2,
CCU RET3
, CCU RET4
RET1 SW + RET2 SW RET1 SW
, RET3 SW Changes operation when you press both the RET 1
button and RET 2 button at the same time.
RET1 SW: Functions as the RET 1 button.
RET3 SW: Functions as the RET 3 button.
<HEADSET MIC>
18 (U11)
INTERCOM1 DYNAMIC
, CARBON, MANUAL
LEVEL –60 dB, –50 dB, –40 dB,
–30 dB, –20 dB, (–60 dB)
,
(–50 dB), (–40 dB), (–30 dB),
(–20 dB)
Settings in ( ): With DYNAMIC or CARBON (cannot be
changed)
–6, 0
, 6 dB Input gain
POWER ON, OFF, (ON), (OFF)
Settings in ( ): With DYNAMIC or CARBON (cannot be
changed)
UNBAL ON, OFF, (ON)
, (OFF) Settings in ( ): With CARBON (cannot be changed)
INTERCOM2 DYNAMIC
, CARBON, MANUAL
LEVEL –60 dB, –50 dB, –40 dB,
–30 dB, –20 dB, (–60 dB)
,
(–50 dB), (–40 dB), (–30 dB),
(–20 dB)
Settings in ( ): With DYNAMIC or CARBON (cannot be
changed)
–6, 0
, 6 dB Input gain
POWER ON, OFF, (ON), (OFF)
Settings in ( ): With DYNAMIC or CARBON (cannot be
changed)
UNBAL ON
, OFF, (ON), (OFF) Settings in ( ): With CARBON (cannot be changed)
<INTERCOM1>
19
INTERCOM1 RECEIVE
SELECT
SEPARATE
, MIX
INTERCOM ---, LEFT
, RIGHT, BOTH JN/SY models only
When ENG/PROD is set to MIX, this item is split into
ENG and PROD items (with same setting).
ENG ---, LEFT
, RIGHT, BOTH On JN/SY models, these items are displayed only
when ENG/PROD is set to MIX.
PROD ---, LEFT
, RIGHT, BOTH
PGM1 ---, LEFT, RIGHT
, BOTH
PGM2 ---, LEFT, RIGHT
, BOTH
TRACKER ---, LEFT
, RIGHT, BOTH
SIDE TONE MU, 1 to 99, 50
INTERCOM1/2 SEPARATE, MIX
ENG/PROD SEPARATE
, MIX JN/SY models only.
OPERATION
Page name
Page No.
Item Settings Description
