Sony HT-DDW5000 - Rear panel

9
GB
Getting Started
Rear panel
31 2 1
46 557
DVD IN BD IN OUT
OPTICAL
COAXIAL
BD
IN
SAT
IN
DVD
IN
HDMI
VIDEO
OUT
SAT IN
DVD IN BD IN MONITOR OUT
VIDEO
IN
AUDIO
OUT
AUDIO
IN
VIDEO
IN
AUDIO
IN
VIDEO
IN
AUDIO
IN
AUDIO
OUT
SUBWOOFER
Y
P
B /
C B
P R /
C R
SURROUND
FRONT: ONLY FOR SS-MSP5000
CENTER: ONLY FOR SS-CNP5000
SURROUND: ONLY FOR SS-SRP5000
SURROUND
BACK
CENTER
LR
FRONT
L
R
SPEAKERS
DMPORT
DIGITAL
AM
ANTENNA
L
R
L
R
SA-CD / CD / CD-R
ININOUT
TV SAT DVD VIDEO 1
VIDEO
OUT
MONITOR
COMPONENT VIDEO
DC5V
0.7A MAX
A DIGITAL INPUT/OUTPUT section
OPTICAL
IN jacks
Connects to a DVD
player, etc. The
COAXIAL jack
provides a better
sound quality (page
23, 24).
COAXIAL IN
jack
HDMI IN/
OUT* jacks
Connects to a DVD
player, etc. The
image and the sound
are output to a TV
(page 21).
B ANTENNA section
FM
ANTENNA
jack
Connects to the
supplied FM wire
antenna (page 27).
AM
ANTENNA
terminals
Connects to the
supplied AM loop
antenna (page 27).
C COMPONENT VIDEO INPUT/
OUTPUT section
Y, PB/CB,
P
R/CR IN/
OUT* jacks
Connects to a DVD
player, TV, satellite
tuner, etc. You can
enjoy high quality
image (page 18, 23,
24).
D SPEAKERS section
Connects to the
supplied speakers
(page 16).
Green
(Y)
Blue
(P
B/CB)
Red
(P
R/CR)
continued
