10. Log: Error Log (Output of each Log)
This screen displays the contents of each log.
Note: Do not refer to the displayed date.
Screen 1: Selects log
Operation:
[1]/[ ] Moves to the Error Log output screen
[RETURN] Returns to the top menu of the service mode
Screen 2: Displays the Error Log
Operation:
[
<
] Returns to the previous page
[
,
] Moves to the next page
[RETURN] Returns to the screen (Screen 1) that selects the log
type
[RED] Writes the log contents to an USB memory device
• Viewing the log display
Error Log:
[174] 2010/01/01 00:00:08 [ErrCode:0902A4053002]
[Index number] [Date] [Time] [Error code]
About copying log to USB memory device:
Press the [RED] button in each log display screen with the USB
memory device inserted into the unit.
Note: Please do not press the [RED] button immediately after USB
memory is inserted.
Please do not pull out USB memory immediately after the [RED]
button was pressed.
Error Log:
When “getErrLogFile.trm fi le” exists in the USB memory de-
vice, errlog.log fi le is output.
 Select Log
HELP : [DOWN][ENT][(NUM)]
 Error Log
02]
[174] 2010/01/01 00:00:08 [ErrCode:0902A4053002]
[175] 2010/01/01 00:00:08 [ErrCode:0902A4053002]
[176] 2010/01/01 00:00:08 [ErrCode:0902A4053002]
[177] 2010/01/01 00:00:08 [ErrCode:0902A4053002]
[178] 2010/01/01 00:00:08 [ErrCode:0902A4053002]
[179] 2010/01/01 00:00:08 [ErrCode:0902A4053002]
[180] 2010/01/01 00:00:08 [ErrCode:0902A4053002]
[181] 2010/01/01 00:00:08 [ErrCode:0902A4053002]
[182] 2010/01/01 00:00:08 [ErrCode:0902A4053002]
[183] 2010/01/01 00:00:08 [ErrCode:0902A4053002]
[184] 2010/01/01 00:00:07 [ErrCode:0902A4053002]
[185] 2010/01/01 00:00:08 [ErrCode:0902A4053002]
[186] 2010/01/01 00:00:08 [ErrCode:0902A4053002]
<Page 1/20>
HELP : Press [RED] key to store log to Udisc.
[1] Error Log
(Screen 1)
(Screen 2)
11. Factory Initialize (Factory Settings)
Return all of the unit setting to their factory defaults (Refer to
FACTORY INITIALIZE in page 21).
12. Network (Network Test Diagnosis Screen: Ifconfi g)
Network menu for the wired ethernet.
Note: Not used for the servicing.
13. Network (Network Test Diagnosis Screen: Ping)
Ping test for the wired ethernet.
Note: Not used for the servicing.
14. Version Up Test (Disc Update)
This screen performs version update test.
Note: Not used for the servicing.
15. System Information (System Information Display)
This screen displays system information.
Screen 1: Basic Information
Operation:
[
,
] Basic Information displayed (go to Screen 2)
[RETURN] Returns to service top menu
Screen 2: Basic Information (continue)
Operation:
[
<
] Basic Information displayed (go to Screen 1)
[RETURN] Returns to service top menu

System Information
HELP : [RET] [RIGHT]
(Screen 1)

System Information
WLAN module hw version:
WLAN module MAC Address:
Drive Firm Revision:
WLAN module Serial:
IF_MODEL:
IF_DEST:
Bluetooth Device Address:
HELP : [RET] [LEFT]
(Screen 2)
Main LSIname:
Model:
Destination:
Sequence Number:
MAC:
IP:
IF-con Main Version:
IFCon ADSP Coeff Version:
Bootloader Version:
Host Main Version:
MicroBE Version:
Host Sub Version:
Middleware Version:
ADSP Version:
ADSP Coeff Version:
2nd DSP Version:
ADSP Version:
16. Drive
This menu is used to operate the drive using drive-related diagnos-
tic and tools.
Note: Not used for the servicing.
