Sony HT-NT3 Service Manual

83
HT-NT3
SECTION 7
ELECTRICAL PARTS LIST
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AUS : Australian model
CND : Canadian model
E3 : 240V AC area in E model
EA : Saudi Arabia model
LA9 : Latin-American model
RU : Russian model
SP : Singapore model
TW : Taiwan model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
AMP
A-2060-205-A AMP BOARD, COMPLETE
********************
< CAPACITOR >
C6002 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C6003 1-114-214-81 CERAMIC CHIP 470PF 5% 50V
C6004 1-114-214-81 CERAMIC CHIP 470PF 5% 50V
C6009 1-118-365-11 CERAMIC CHIP 0.047uF 10% 50V
C6010 1-118-365-11 CERAMIC CHIP 0.047uF 10% 50V
C6011 1-118-365-11 CERAMIC CHIP 0.047uF 10% 50V
C6012 1-118-365-11 CERAMIC CHIP 0.047uF 10% 50V
C6013 1-114-214-81 CERAMIC CHIP 470PF 5% 50V
C6014 1-114-214-81 CERAMIC CHIP 470PF 5% 50V
C6015 1-118-692-11 ELECT CHIP 470uF 20% 35V
C6016 1-118-692-11 ELECT CHIP 470uF 20% 35V
C6017 1-118-044-11 CERAMIC CHIP 1uF 10% 50V
C6018 1-118-044-11 CERAMIC CHIP 1uF 10% 50V
C6021 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C6022 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C6023 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
C6024 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
C6025 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C6026 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
C6031 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
* C6032 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
* C6033 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
* C6034 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C6035 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C6036 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C6037 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C6038 1-118-395-11 CERAMIC CHIP 0.0047uF 10% 50V
C6039 1-118-395-11 CERAMIC CHIP 0.0047uF 10% 50V
C6040 1-118-388-11 CERAMIC CHIP 0.047uF 10% 25V
C6041 1-118-388-11 CERAMIC CHIP 0.047uF 10% 25V
* C6042 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
* C6043 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
C6044 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C6045 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
C6046 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C6048 1-118-395-11 CERAMIC CHIP 0.0047uF 10% 50V
C6054 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C6055 1-116-731-11 CERAMIC CHIP 2.2uF 20% 6.3V
* C6062 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
C6063 1-116-874-11 CERAMIC CHIP 10uF 10% 35V
C6065 1-118-399-11 CERAMIC CHIP 0.0022uF 10% 50V
C6066 1-116-711-11 CERAMIC CHIP 22uF 20% 16V
C6067 1-116-711-11 CERAMIC CHIP 22uF 20% 16V
C6073 1-116-874-11 CERAMIC CHIP 10uF 10% 35V
C6074 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C6078 1-120-069-71 FILM 0.22uF 99% 450V
C6079 1-120-069-71 FILM 0.22uF 99% 450V
C6080 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C6081 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C6082 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C6083 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C6084 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C6085 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
* C6087 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
C6088 1-114-385-11 ELECT CHIP 470uF 20% 6.3V
C6089 1-116-874-11 CERAMIC CHIP 10uF 10% 35V
C6090 1-116-874-11 CERAMIC CHIP 10uF 10% 35V
C6091 1-118-399-11 CERAMIC CHIP 0.0022uF 10% 50V
C6092 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C6094 1-116-711-11 CERAMIC CHIP 22uF 20% 16V
C6095 1-116-711-11 CERAMIC CHIP 22uF 20% 16V
C6096 1-116-711-11 CERAMIC CHIP 22uF 20% 16V
C6099 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
C6100 1-117-681-11 ELECT CHIP 100uF 20% 16V
C6101 1-116-740-11 CERAMIC CHIP 0.47uF 10% 16V
C6102 1-116-740-11 CERAMIC CHIP 0.47uF 10% 16V
< CONNECTOR >
CN6001 1-779-993-11 PIN, CONNECTOR (PWB) 5P
Note: When the C6078 and C6079 on the AMP board are
replaced, spread the bond referring to “BOND FIXATION
OF ELECTRIC PARTS” on page 5.
Ver. 1.1
