Sony HT-NT3 Service Manual

HT-NT3
HT-NT3
4848
5-20. PRINTED WIRING BOARD - AUDIO IO Board -
• See page 31 for Circuit Boards Location. • : Uses unleaded solder.
5-21. SCHEMATIC DIAGRAM - AUDIO IO Board -
1
A
B
C
D
E
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
2
19
8
CN1300
C1300
C1301 R1302
C1302
R1303
R1307
C1308
C1309
J1301
213
IC1301
D1300
C3001
C3002
R1309
R1310
R1311
R1312
CL1305
CL1308
CL1303
CL1302
CL1304
CL1306
CL1300
CL1301
CL1307
CL1309
CL1310
ANALOG
IN
TV
DIGITAL IN
>001P
MB-1407 BOARD
CN705
(Page 32)
>011P
MB-1407 BOARD
CN705
(Page 33)
1-893-934-
11
(11)
AUDIO IO BOARD
(COMPONENT SIDE)
1-893-934-
11
(11)
AUDIO IO BOARD
(CONDUCTOR SIDE)
EXCEPT
AEP, UK, RU, AUS
AEP, UK, RU, AUS
1
A
B
C
D
E
2 3 4 5 67
AUDIO IO BOARD
47
C1308
0.1
C1309
47p
C1301
47p
C1302
15k
R1302
15k
R1303
CL1302
CL1307
CL1300
CL1305
CL1308
CL1301
CL1304
CL1306
CL1303
9P
CN1300
1AGND
2L_CH
3AGND
4R_CH
5AGND
6A5V
7D3.3V
8OPT_IN
9DGND
100
R1307
J1301
VOUT
GND
VCC
0.1
C1300
BAV99-215
D1300
CL1309
CL1310
18k
R1309
2.2k
R1311
18k
R1310
10
C3002
10
C3001
2.2k
R1312
3
2
1
IC1301
JSR1124
DIGITAL OPTICAL
RECEIVER
IC1301
>046S
MB-1407
BOARD
(7/12)
CN705
(Page 40)
ANALOG
IN
TV
DIGITAL IN
Ver. 1.1

Sony HT-NT3 Specifications

General

Output power	400 W
Apple docking compatibility	Not supported
HDMI in	3
Bluetooth	Yes
HDMI ports quantity	4
Number of HDMI outputs	1
Connectivity technology	Wired & Wireless
Number of amplifier channels	2.1 channels
Audio decoders	Dolby Digital Plus, Dolby Dual Mono, Dolby TrueHD, DTS, DTS 96/24
Subwoofer location	Separate
Receiver included	No
Product color	Black

Weight and Dimensions

Depth	65 mm
Width	1070 mm
Height	86 mm
Soundbar weight	3100 g
Subwoofer depth	382 mm
Subwoofer width	190 mm
Subwoofer height	385 mm
Subwoofer weight	8000 g
