Sony HT-NT3 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-NT3
84
AMP AUDIO IO
CN6002 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P
CN6004 1-815-763-32 CONNECTOR, FFC/FPC 24P
CN6007 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P
CN6008 1-816-296-21 PIN, CONNECTOR (PC BOARD) 9P
< IC >
IC6001 6-721-742-01 IC TAS5614LA
IC6002 6-718-105-01 IC TAS5534DGGR
IC6003 6-721-694-01 IC RT7272BGSP
IC6004 6-721-694-01 IC RT7272BGSP
< JUMPER RESISTOR >
JC6001 1-216-864-11 SHORT CHIP 0
JC6002 1-216-864-11 SHORT CHIP 0
JC6003 1-216-864-11 SHORT CHIP 0
JC6004 1-216-864-11 SHORT CHIP 0
JC6005 1-216-864-11 SHORT CHIP 0
JC6011 1-216-864-11 SHORT CHIP 0
< COIL >
L6005 1-469-555-21 INDUCTOR 10uH
L6009 1-460-601-11 INDUCTOR 10uH
L6010 1-400-789-21 INDUCTOR 2.2uH
L6011 1-400-789-21 INDUCTOR 2.2uH
L6012 1-460-601-11 INDUCTOR 10uH
< TRANSISTOR >
Q6004 6-550-585-01 TRANSISTOR 2PC4081R-115
Q6005 8-729-013-22 TR HN1A01FU
Q6007 6-552-974-01 TR RZM001P02T2L
Q6008 6-552-936-01 TR LTC014EUBFS8TL
< RESISTOR >
R6001 1-208-922-11 METAL CHIP 30K 0.5% 1/16W
R6002 1-218-937-11 METAL CHIP 47 5% 1/16W
R6003 1-218-937-11 METAL CHIP 47 5% 1/16W
R6004 1-218-937-11 METAL CHIP 47 5% 1/16W
R6005 1-218-937-11 METAL CHIP 47 5% 1/16W
R6011 1-216-001-00 METAL CHIP 10 5% 1/10W
R6012 1-216-001-00 METAL CHIP 10 5% 1/10W
R6013 1-216-001-00 METAL CHIP 10 5% 1/10W
R6014 1-216-001-00 METAL CHIP 10 5% 1/10W
R6025 1-218-967-11 METAL CHIP 15K 5% 1/16W
R6026 1-250-525-11 METAL CHIP 18K 1% 1/16W
R6027 1-250-487-11 METAL CHIP 470 1% 1/16W
R6028 1-250-487-11 METAL CHIP 470 1% 1/16W
R6035 1-218-937-11 METAL CHIP 47 5% 1/16W
R6036 1-218-937-11 METAL CHIP 47 5% 1/16W
R6037 1-218-937-11 METAL CHIP 47 5% 1/16W
R6039 1-218-937-11 METAL CHIP 47 5% 1/16W
R6043 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6044 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6045 1-218-937-11 METAL CHIP 47 5% 1/16W
R6049 1-218-977-11 METAL CHIP 100K 5% 1/16W
R6050 1-218-977-11 METAL CHIP 100K 5% 1/16W
R6056 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6059 1-218-971-81 METAL CHIP 33K 5% 1/16W
R6060 1-218-971-81 METAL CHIP 33K 5% 1/16W
R6065 1-216-845-11 METAL CHIP 100K 5% 1/10W
R6066 1-216-839-11 METAL CHIP 33K 5% 1/10W
R6067 1-208-920-81 METAL CHIP 24K 0.5% 1/16W
R6072 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R6076 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R6084 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6085 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R6089 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R6090 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R6091 1-216-295-91 SHORT CHIP 0
R6092 1-216-295-91 SHORT CHIP 0
R6093 1-216-295-91 SHORT CHIP 0
R6094 1-216-295-91 SHORT CHIP 0
R6095 1-216-295-91 SHORT CHIP 0
R6096 1-216-295-91 SHORT CHIP 0
R6097 1-216-295-91 SHORT CHIP 0
R6098 1-216-295-91 SHORT CHIP 0
R6099 1-216-845-11 METAL CHIP 100K 5% 1/10W
R6100 1-216-839-11 METAL CHIP 33K 5% 1/10W
R6101 1-218-967-11 METAL CHIP 15K 5% 1/16W
R6102 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R6103 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R6106 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R6107 1-216-793-11 METAL CHIP 4.7 5% 1/10W
< COMPOSITION CIRCUIT BLOCK >
RB6001 1-234-381-11 RES, NETWORK 100K (1005X4)
RB6002 1-234-372-11 RES, NETWORK 100 (1005X4)
RB6003 1-234-372-11 RES, NETWORK 100 (1005X4)
*************************************************************
A-2060-206-A AUDIO IO BOARD, COMPLETE
************************
< CAPACITOR >
C1300 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C1301 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C1302 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C1308 1-116-707-11 CERAMIC CHIP 47uF 20% 10V
C1309 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
* C3001 1-116-719-11 CERAMIC CHIP 10uF 10% 6.3V
* C3002 1-116-719-11 CERAMIC CHIP 10uF 10% 6.3V
< CONNECTOR >
CN1300 1-820-112-51 CONNECTOR, FFC/FPC 9P
< DIODE >
D1300 6-500-400-01 DIODE BAV99-215
< IC >
IC1301 6-600-827-01 IC JSR1124 (TV DIGITAL IN)
< JACK >
J1301 1-566-822-61 JACK (ANALOG IN)
< RESISTOR >
R1302 1-218-967-11 METAL CHIP 15K 5% 1/16W
R1303 1-218-967-11 METAL CHIP 15K 5% 1/16W
R1307 1-218-941-81 METAL CHIP 100 5% 1/16W
R1309 1-218-968-11 METAL CHIP 18K 5% 1/16W
R1310 1-218-968-11 METAL CHIP 18K 5% 1/16W
R1311 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
Note: When the IC6001 on the AMP board is replaced, refer
to “NOTE OF REPLACING THE IC6001 ON THE AMP
BOARD AND THE COMPLETE AMP BOARD” on page 5.
Ver. 1.1

Sony HT-NT3 Specifications

General

Output power	400 W
Apple docking compatibility	Not supported
HDMI in	3
Bluetooth	Yes
HDMI ports quantity	4
Number of HDMI outputs	1
Connectivity technology	Wired & Wireless
Number of amplifier channels	2.1 channels
Audio decoders	Dolby Digital Plus, Dolby Dual Mono, Dolby TrueHD, DTS, DTS 96/24
Subwoofer location	Separate
Receiver included	No
Product color	Black

Weight and Dimensions

Depth	65 mm
Width	1070 mm
Height	86 mm
Soundbar weight	3100 g
Subwoofer depth	382 mm
Subwoofer width	190 mm
Subwoofer height	385 mm
Subwoofer weight	8000 g
