Sony HT-NT3 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-NT3
86
C313 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
* C314 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C315 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C316 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
* C317 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C318 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C325 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C326 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C327 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C328 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C329 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C330 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
* C331 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C332 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C333 1-116-736-11 CERAMIC CHIP 1uF 10% 10V
C334 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C335 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
* C336 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C337 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C338 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C339 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C340 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C341 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C342 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C344 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C347 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C351 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C352 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C353 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
* C354 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C355 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C356 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C362 1-116-709-11 CERAMIC CHIP 22uF 10% 25V
C402 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C404 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C405 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C406 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C407 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C408 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C409 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C410 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
(AEP, UK, RU, AUS)
C411 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C412 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C413 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C414 1-116-719-11 CERAMIC CHIP 10uF 10% 6.3V
C415 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C416 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
(AEP, UK, RU, AUS)
C417 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C418 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C419 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C420 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C421 1-116-719-11 CERAMIC CHIP 10uF 10% 6.3V
C422 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C423 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C424 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C425 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C426 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C427 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C428 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C429 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU, AUS)
C430 1-164-852-11 CERAMIC CHIP 12PF 5% 50V
(EXCEPT AEP, UK, RU, AUS)
C431 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
(AEP, UK, RU, AUS)
C431 1-164-852-11 CERAMIC CHIP 12PF 5% 50V
(EXCEPT AEP, UK, RU, AUS)
C433 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C434 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C435 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C436 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU, AUS)
C437 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU, AUS)
C439 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU, AUS)
* C501 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
* C502 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
* C503 1-116-719-11 CERAMIC CHIP 10uF 10% 6.3V
* C504 1-116-719-11 CERAMIC CHIP 10uF 10% 6.3V
C505 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
C506 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C507 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C509 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
* C510 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C511 1-116-719-11 CERAMIC CHIP 10uF 10% 6.3V
* C512 1-116-719-11 CERAMIC CHIP 10uF 10% 6.3V
C519 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU, AUS)
* C520 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
C521 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C522 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
C525 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C526 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C527 1-114-472-91 CERAMIC CHIP 0.001uF 10% 2KV
C528 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C529 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C530 1-116-736-11 CERAMIC CHIP 1uF 10% 10V
C531 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C532 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C533 1-116-736-11 CERAMIC CHIP 1uF 10% 10V
C534 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C535 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
C536 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C537 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C538 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU, AUS)
C539 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU, AUS)
C601 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C602 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU, AUS)
C603 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C604 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU, AUS)
C605 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU, AUS)
C606 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C607 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU, AUS)
C608 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
MB-1407
Ver. 1.1

Sony HT-NT3 Specifications

General

Output power	400 W
Apple docking compatibility	Not supported
HDMI in	3
Bluetooth	Yes
HDMI ports quantity	4
Number of HDMI outputs	1
Connectivity technology	Wired & Wireless
Number of amplifier channels	2.1 channels
Audio decoders	Dolby Digital Plus, Dolby Dual Mono, Dolby TrueHD, DTS, DTS 96/24
Subwoofer location	Separate
Receiver included	No
Product color	Black

Weight and Dimensions

Depth	65 mm
Width	1070 mm
Height	86 mm
Soundbar weight	3100 g
Subwoofer depth	382 mm
Subwoofer width	190 mm
Subwoofer height	385 mm
Subwoofer weight	8000 g
