117
Quick Reference
HVR-A1E/A1P 2-639-668-11(1)
Continued
Microphone (19)
XLR adaptor (19)
Lens cover lever (20)
Lens hood with lens cover (9, 20)
Zoom buttons (24)
REC START/STOP button (22)
LCD screen/touch panel (4, 15)
HDV/DV Interface (i.LINK) jack (76)
(USB) jack (76)
DISPLAY/BATT INFO button (27)
COMPONENT OUT jack (76)
A/V OUT jack (76)
INPUT1 LOW CUT switch (20)
INPUT2 LOW CUT switch (20)
RESET button (27)
Eyecup
Viewfinder (14)
Viewfinder lens adjustment lever (14)
LANC jack (76)
CHG (charge) lamp (10)
Speaker (27)
AUTO LOCK switch (25)
Battery pack (10)
DC IN jack (76)
Attaching the shoulder strap
Attach the shoulder strap supplied with
your camcorder to the hooks for the
shoulder strap.
To Next Page
